Operating instructions
AS-i module
UK
AC2218
AC2219

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ecomot 300 AC2219 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for IFM Electronic ecomot 300 AC2219

  • Page 1 Operating instructions AS-i module AC2218 AC2219...
  • Page 2: Table Of Contents

    Contents 1 Preliminary note ���������������������������������������������������������������������������������������������������3 2 Safety instructions �����������������������������������������������������������������������������������������������3 3 Functions and features ����������������������������������������������������������������������������������������3 4 Addressing �����������������������������������������������������������������������������������������������������������4 4�1 Addressing with the AC1154 addressing unit�������������������������������������������������4 5 Mounting ��������������������������������������������������������������������������������������������������������������4 6 Electrical connection ��������������������������������������������������������������������������������������������4 6�1 Wiring�������������������������������������������������������������������������������������������������������������5 6�2 Connection analogue module AC2218 (0���20 mA) ���������������������������������������5 6�2�1 Connection of an actuator without separate voltage supply �����������������5 6�2�2 Connection of an actuator with intrinsic supply �����������������������������������6 6�2�3 Connection of an actuator with separate 24 V supply ��������������������������6...
  • Page 3: Preliminary Note

    1 Preliminary note ► Instructions > Reaction, result Important note Non-compliance can result in malfunction or interference� Information Supplementary note� 2 Safety instructions • Please read the operating instructions prior to set-up of the device� Ensure that the product is suitable for your application without any restrictions� •...
  • Page 4: Addressing

    • 16 bits/1 µA (AC2218) or 16 bits / 1 mV (AC2219) 4 Addressing ► Assign a free address between 1 and 31� The address is set to 0 at the factory� 4.1 Addressing with the AC1154 addressing unit ► When mounted and wired the module can be addressed with the addressing cable (E70213) via the integrated addressing interface�...
  • Page 5: 6�1 Wiring

    6.1 Wiring AC2218 AC2219 Actuator supply +24 V O+ C1 O-0V O+ V1 O- 0V C2 O-0V V2 O- 0V C1���C4 Analogue output current C3 O-0V V3 O- 0V (AC2218) V1���V4 Analogue output voltage (AC2219) Actuator supply 0 V Analogue output 0 V AS-i + AS-i - External actuator supply...
  • Page 6: 6�2�2 Connection Of An Actuator With Intrinsic Supply

    6.2.2 Connection of an actuator with intrinsic supply C1...C4 A 2-wire actuator is connected via the terminals C1��C4 and 0 V� The terminals O+ and O- are not used with actuators without separate voltage supply� 1: Analogue module 2: Actuator with intrinsic supply 3: Supply PELV ungrounded 6.2.3 Connection of an actuator with separate 24 V supply An actuator with separate supply is...
  • Page 7 Example This problem can occur when a frequency converter is connected, i�e� the connection of the 0 V- terminal is established there (common-)� ► Adhere to the documentation of the frequency converter� AC2xx8 1: Frequency converter ► As a remedy, use two current output modules�...
  • Page 8: 6�3 Connection Analogue Module Ac2219 (0

    6.3 Connection analogue module AC2219 (0...10 V) 6.3.1 Connection of an actuator with intrinsic supply V1...V4 An actuator with intrinsic supply (e�g� a voltmeter) is connected via the terminals V1��V4 and O-� 1: Analogue module 2: Actuator with intrinsic supply 3: Supply PELV ungrounded 6.3.2 Connection of an actuator with separate 24 V supply An actuator with separate supply is...
  • Page 9: Parameter Setting

    7 Parameter setting Parameter bit / Designation Description 1 reserved not used 0 reserved 1 reserved not used 0 reserved 1 error indication active periphery fault 0 error indication inactive 1 reserved not used 0 reserved 8 Measuring range ► The measuring ranges, the states of the LEDs and their meaning are indicated in the following tables�...
  • Page 10: 8�3 Transmission Time Of The Analogue Values

    8.3 Transmission time of the analogue values The transmission time of the analogue values depends on the conversion time of the digital signals into analogue signals in the AS-i module and on the transmission time via the AS-Interface� The conversion time of the digital signals is approx� 1 ms� The transmission time of the 4 16-bit values via the AS-interface ideally is 7 AS-i cycles per value�...
  • Page 11: Maintenance, Repair And Disposal

    10 Maintenance, repair and disposal The operation of the unit is maintenance-free� After use dispose of the unit in an environmentally friendly way in accordance with the applicable national regulations� 11 Technical data Technical data and further information at www�ifm�com 12 Scale drawing 1: LEDs 2: Addressing socket...
