N
Panduit Part Numbers: CRB6BL, CRTB
© Panduit Corp. 2007
2x
CRB6BL
Typical: 4 Places
¼-20x1 Hex Slotted
Washer Head Machine
Screw
FR716DR
Typical: 4 Places
-A
Overhead Cable Routing System
ET
CCESS
INSTALLATION INSTRUCTIONS
2x
N
-A
ET
CCESS
FR38DR
¼-20 Hex Washer
Lock Nut
For Technical Assistance, Call: 800-777-3300
1
Network Cabinet
2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panduit CRB6BL
Summary of Contents for Panduit CRB6BL
- Page 1 Overhead Cable Routing System CCESS Panduit Part Numbers: CRB6BL, CRTB INSTALLATION INSTRUCTIONS © Panduit Corp. 2007 CRB6BL Network Cabinet CCESS Typical: 4 Places FR38DR ¼-20x1 Hex Slotted Washer Head Machine Screw FR716DR ¼-20 Hex Washer Lock Nut Typical: 4 Places...
- Page 2 INSTALLATION INSTRUCTIONS CRTB For Technical Assistance, Call: 800-777-3300...
- Page 3 INSTALLATION INSTRUCTIONS Typical: 4 Places FR38DR ¼-20x1 Hex Slotted Washer Head Machine Screw FR716DR ¼-20 Hex Washer Lock Nut Typical: 4 Places ¼-20x Hex Head Cap Screw ¼ Helical Spring Lockwasher FR716DR ¼ SAE Flat Washer Typical: Both Sides For Technical Assistance, Call: 800-777-3300...
- Page 4 -or- 12x4 IBER UNNER Ladder Rack -or- Cable Tray -or- Wire Basket Instruction Sheet RW230 WORLDWIDE SUBSIDIARIES AND SALES OFFICES 17301 Ridgeland Avenue Fax: 708-532-1811 Tinley Park, IL 60477-3901 Technical Support: 800-777-3300 Web Site: www.panduit.com E-mail: cs@panduit.com RACEWAY SYSTEMS DIVISION...
- Page 5 INSTALLATION INSTRUCTIONS Mounting Hole Location - Top* 6.00” (152.4mm) 12.75” (323.9mm) 0.38” - 0.50” (9.7mm - 12.7mm) dia 6.25” (158.8mm) 1.00” (25.4mm) 27.54” (699.5mm) Front * If the N Network Cabinet was supplied without the four (4) required pre-drilled mounting holes, the installer must drill four (4) 0.38” - 0.50” dia CCESS holes at the locations specified above.
