- Page 1 ® DataMan 8072 DL Quick Reference Guide 2019 October 08 Revision: 6.1.6SR1.5...
- Page 2 Precautions To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: Route cables and wires away from high-current wiring or high-voltage power sources to reduce the risk of damage or malfunction from the following causes: over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply.
-
Page 3: Product Overview
Product Overview Illumination module LED aimers Illumination LEDs Trigger (press and hold to read) Lanyard hook Indicator light Communication module insertion point... -
Page 4: Base Station Overview
Base Station Overview Base station status indicators PAIR sticker - Reading the code pairs the base station with the device Connection point to the reader: pairing reader and base station non-wireless communication charging RS-232 Power plug (24V, max. 15W) Alternative power supply connector (24V, max. 15W, polarity marked on the plastic part near the connector). - Page 5 DataMan 8072 DL Accessories Serial/USB slide-in DMCM-SERIALM-00 Ethernet slide-in DMCM-ENETM-00 Bluetooth slide-in DMCM-BTM-00 Charging base station DMA-CBASE-01 Intelligent Bluetooth base station DMA-IBASE-BT-02 Power Supply for base station DMA-24VPWR-xx* Power Supply for reader DM100-PWR-000 DMA-HHBATTERY-01 Battery for the wireless reader Multi-battery charger...
- Page 6 Cables Coiled RS-232 cable for reader, 2.5 m DM8000-RS232-02 Industrial RS-232 cable for reader, 2.5 m DM8000-RS232IND-02 Coiled RS-232 cable for reader, 4 m DM8000-RS232-05 Coiled USB cable, 2.5 m DM8500-USBC-02 Ethernet cable, 2.5 m DM8000-ECABLE-02 Ethernet cable, 30 m DM8000-ECABLE-30 Ethernet cable, 5 m DM8000-ECABLE-05...
-
Page 7: Field Of View And Reading Distances
Field of View and Reading Distances DataMan 8072 DL with a 6.2 mm Lens (Standard Range, Focused to 75 mm) Device Distances in mm/1D min. code Distances in mm/2D min. code DM8072 20-170 6 MIL 0-200 10 MIL 0-200 10 MIL... - Page 8 Connecting the Reader Bluetooth Readers 1. Connect the slide-in to the reader and tighten the screws to lock the slide-in. 2. Insert the battery. 3. Insert the plug. Corded Readers 1. Connect the slide-in to the reader and tighten the screws to lock the slide-in. 2.
-
Page 9: Installation
DataMan system; do not force the connectors or damage may occur. Install Software and Documentation and Connect the Reader To configure a DataMan 8072 DL reader, the DataMan Setup Tool software must be installed on a networked PC. The DataMan Setup Tool is available from the DataMan support site: http://www.cognex.com/support/dataman. - Page 10 DataMan 8072 Specifications 254 g (without slide-in) Weight 0ºC — 40ºC (32ºF — 104ºF) Operating Temperature -10ºC — 60ºC (14ºF — 140ºF) Storage Temperature Maximum Humidity < 95% (non-condensing) Environemntal IP65 1-D barcodes: Codabar, Code 39, Code 128, and Code 93, Interleaved 2 of 5, Codes Pharma, GS1 DataBar, Postal, UPC/EAN/JAN, DataBar 2-D barcodes: Data Matrix...
-
Page 11: Dataman Base Station Specifications
DataMan Base Station Specifications DMA-IBASE-BT-02 Weight 300 g Operating Temperature 0ºC — 45ºC (32ºF — 113ºF) Storage Temperature -40ºC — 60ºC (-40ºF — 140ºF) Maximum Humidity 95% (non-condensing) 24V +-10%, 15 W maximum LPS or NEC class 2 power supply Power Supply Recommended wire diameter is 14-18 AWG Requirements... - Page 12 Please read these guidelines carefully before using your device. Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. Regulator Specification FCC Part 15B, Class A...
- Page 13 A est conforme à la norme NMB-003 du Canada. LED Safety Statement For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE).
- Page 14 The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration.
- Page 15 Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. Please read these guidelines carefully before using your device. Safety and Regulatory...
- Page 16 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made to this equipment not expressly approved by Cognex may void the FCC authorization to operate this equipment. Canadian Compliance This Class A digital apparatus complies with Canadian ICES-003.
- Page 17 In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal. Those systems will reuse or recycle most of the materials of the product you are disposing in a sound way. The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal.
- Page 18 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
- Page 19 Copyright © 2019 Cognex Corporation. All Rights Reserved.
