- Page 1 ® DataMan 8072 Verifier Quick Reference Guide 06/07/2018 Revision:5.7.7.140...
- Page 2 LASER PRODUCT. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE SERIOUS INJURY. Observe these precautions when installing the Cognex product, to reduce the risk of injury or equipment damage: To reduce the risk of damage or malfunction due to over-voltage, line noise,...
-
Page 3: Product Overview
Product Overview WARNING: LASER LIGHT, DO NOT STARE INTO BEAM Imager and Lens Optical System Illumination Removable Standoff Trigger (press and release) Lanyard hook Indicator light Communication module insertion point Status indicators: Communication: GREEN= good verification RED = bad verification... - Page 4 DataMan 8072V Kits The DataMan 8072V Verifier is available in the following kits: Model number Description DMV-8072V-S-0200 DataMan 8072V Verifier Ethernet Kit with Stand: - 8072V Verifier - Standoff - Ethernet Slide-In - Ethernet Cable Attachment - Standard Ethernet Cable - POE Injector - Basic Calibration Card - Stand Accessory...
- Page 5 DMV-8072V-0000 DataMan 8072V Verifier Kit No Slide-In - 8072V Verifier - Standoff - Basic Calibration Card DMV-8072V-S-0000 DataMan 8072V Verifier Kit with Stand No Slide-In - 8072 Verifier - Standoff - Stand Accessory - Basic Calibration Card DataMan 8072V verifier and stand-off Ethernet or USB slide-in Stand accessory Calibration card...
- Page 6 DataMan 8072V Verifier Accessories Ethernet slide-in DMCM-ENETM-00 Serial/USB 2.0 slide-in DMCM-USB2EN-00 Power Supply for USB 2.0 Slide-In DM100-PWR-000 POE hub CPS-AC-POE1A-US DMV-8072V-STAND Stand Accessory Cables USB Cable for USB 2.0 Slide-In, 2.5 m DM8500-USBC-02 Ethernet Cable for Ethernet Slide-In, 5 m DM8000-ECABLE-05 Standard Ethernet Cable CBL-C10E...
- Page 7 Connecting the Verifier Note: Disconnect the DataMan 8072V Verifier from power or remove the battery before inserting/removing the communication modules.
-
Page 8: Installation
Installation procedures and specifications are presented in detail in the DataMan 8072 Verifier Reference Manual, which is installed with the DataMan Setup Tool. From the Windows Start menu, select the following to access the manual: All Programs > Cognex > DataMan Software vx.x.x > Documentation. Note: Cables are sold separately. - Page 9 DataMan 8072V Verifier Specifications 400 g (including grip assembly with battery) Weight Operating Temperature 0ºC — 45ºC (32ºF — 113ºF) 0ºC — 60ºC (32ºF — 140ºF) Storage Temperature Maximum Humidity 95% (non-condensing) Environemntal IP65 2-D barcodes: Data Matrix (IDMax and IDQuick: ECC200) Codes USB: bus powered (optionally: external 6W max LPS or NEC class 2 power supply +5V Power Supply...
- Page 10 LED Wavelengths The following table shows LED types and the related wavelengths: λ [nm]...
- Page 11 Please read these guidelines carefully before using your device. Note: For the most up-to-date CE declaration and regulatory conformity information, please refer to the Cognex online support site: http://www.cognex.com/Support. Regulator...
- Page 12 Directive. For further information please contact: Cognex Corporation, One Vision Drive Natick, MA 01760 USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked. FCC Class A This device complies with Part 15 of the FCC Rules.
-
Page 13: For European Community Users
Class 2 Laser device. For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). - Page 14 You may also contact your supplier for more information on the environmental performance of this product.
- Page 15 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
- Page 16 Copyright © 2018 Cognex Corporation. All Rights Reserved.
