Luma Surveillance 310 Series Quick Start Manual

Dome ip surveillance camera
Hide thumbs Also See for 310 Series:

Advertisement

Table of Contents

See also: Operation & Installation Manual
310 Series Dome
IP Surveillance Camera
Quick-Start
Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 310 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Luma Surveillance 310 Series

Summary of Contents for Luma Surveillance 310 Series

  • Page 1 310 Series Dome IP Surveillance Camera Quick-Start Guide...

  • Page 2: Box Contents

    You must provide: A network connection (and an NVR, if desired) Admin rights to a computer that can access the network Mobile device with Luma Surveillance app (recommended) Power source: PoE or 12V DC Phillips screwdriver WARNING: This product can expose you to chemicals including cadmium, which is known to the State of California to cause cancer.
  • Page 3 NVR or through a network router. a powerful remote maintenance tool (see OvrC.com) and lets you use the Luma Surveillance mobile app to check on the camera from anywhere. For installation using this guide, you must be able to access this camera through a personal computer.

  • Page 4: Safety Tips

    Luma 310 Series Dome Camera Safety Tips Handle this device with care. Do not strike or shake this device. Protect the power cord from being stepped on or pinched, particularly where it connects to the device and the power outlet.
  • Page 5 Luma 310 Series Dome Camera Precautions Before you start, ensure that the device is in good condition and all the assembly parts are included. Also ensure that your recorder has the very latest firmware. Use OvrC to update the firmware, or consult your NVR manual.

  • Page 6: Your Camera

    Luma 310 Series Dome Camera Your Camera Before installing, familiarize yourself with your camera. Reset Button Dome Cover Microphone Foam Ring 12VDC Lens Alarm/ Audio Socket SD Card Slot...
  • Page 7 Luma 310 Series Dome Camera Preserving Your Camera Foam Ring CAUTION: Do not throw away the foam ring around the camera lens! It protects the camera from glare from its infrared lights. Protective Film The dome cover comes with a protective film. Do not remove this until you are done installing your camera;...
  • Page 8 Luma 310 Series Dome Camera Installation with an NVR If you are installing with an NVR, follow these instructions. Otherwise, follow the instructions starting on the next page. 1. Ensure your NVR has the latest firmware. If it does not, your NVR may be unable to locate and activate your camera.
  • Page 9 (prior to physical installation), rather than from atop a ladder. Connect the camera to your PC and run the Luma Utility. It searches for attached Luma Surveillance devices. If your camera does not appear, check the connection, ensure the camera is powered up, then...

  • Page 10: Activate The Camera

    Luma 310 Series Dome Camera Activate the Camera Click on the entry for your camera to view its details. If the camera is inactive, use the text boxes at the lower right of the Luma utility window to activate the camera by creating a new secure password.

  • Page 11: Physical Installation

    Luma 310 Series Dome Camera Physical Installation 1. Drill pilot holes for your screws using the supplied template. 2. CAUTION! Before terminating the cable for an outdoor install, you must weatherproof it! See the following pages for details. 3. Remove the protective dome from the camera.
  • Page 12 Luma 310 Series Dome Camera Weatherproofing the PoE Cable 1. Slide the unterminated cable through the lock nut , the Œ rubber gasket Ž, and the weatherproof endcap. Face the notched side of the rubber gasket toward the endcap, as shown.
  • Page 13 Luma 310 Series Dome Camera Start the Web Interface Open your browser and navigate to the camera’s IP address. Below the login area, you may see: “Please click here to download and install the plug-in. Close the browser when installing the plug- in.”...
  • Page 14 Luma 310 Series Dome Camera Check the Camera After logging in, your screen shows the live page, similar to the illustration below. If it does not appear, check the connection to your NVR or network, and ensure that the camera is powered up.

  • Page 15: Adjust The Camera

    Luma 310 Series Dome Camera Adjust the Camera This camera can spin 360° around the base. It can be angled up to 80°. In addition, the camera can rotate 360° within its housing. 1. Swivel the camera so it faces the desired direction.
  • Page 16 For information, instructional videos, support documentation, or ideas, visit our website. 3-Year Limited Warranty This Luma Surveillance™ product has a 3-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use.
