- Page 1 300 Series Bullet HD Analog Surveillance Camera Installation & Operation Manual...
-
Page 2: Installation
Luma 300 Series Bullet Camera Installation Before you start, ensure that the device is in good condition and all the assembly parts are included. Make sure that all equipment is powered off during installation. Ensure the wall is strong enough to hold three times the weight of the camera and the mount. - Page 3 Luma 300 Series Bullet Camera Wiring Advisory We recommend installing this 300-series camera using RG-59 or RG-6 cabling with two-wire power (either regular or siamese). This provides better performance over distance than using traditional category cable with baluns. For more details on the cameras or cables, see the...
-
Page 4: Box Contents
Luma 300 Series Bullet Camera Box Contents Camera Self-adhesive mounting template 4 x wall anchors with screws 3mm hex wrench CC tester cable Required Equipment Aside from the contents of this box, you will need to provide: Phillips screwdriver Power source: 12V DC... - Page 5 Luma 300 Series Bullet Camera Overview Before installing, familiarize yourself with the parts of your camera. This camera has several special features shown here: Focus Dial Zoom Dial Access Panel...
- Page 6 Luma 300 Series Bullet Camera Sunshade Adjustment Screw (not visible) Level Elbow Base Sunshade Screw Screw Screw CVBS/HD-TVI BNC Video Cable Power Cable...
-
Page 7: Prepare For Installation
Luma 300 Series Bullet Camera Prepare for Installation 1. Drill a cable hole and pilot holes for your screws in the ceiling, using the supplied template. 2. If you are installing a 300-series camera in an older system that doesn’t support HD-TVI, unscrew the access panel cap and flip the camera’s resolution toggle, shown below, to the... -
Page 8: Install The Camera
Luma 300 Series Bullet Camera Install the Camera 3. Attach the base of the camera to the ceiling and secure it with screws. 4. Route the cables through the cable hole. 5. This camera has an elbow joint flanked by two rotational joints for perfect pan and tilt control. - Page 9 Luma 300 Series Bullet Camera 6. Rotate the camera so that it faces in the proper direction, and tighten the base screw, B. Finally, spin the camera casing so that the picture is level, and tighten the level hex screw, C.
-
Page 10: Adjust The Camera
Luma 300 Series Bullet Camera Adjust the Camera 1. Adjust or remove the sunshade. You can slide the shade back and forth by loosening the screw slightly; tighten when finished. You can remove the shade by removing the screw, then removing the shade;... - Page 11 Luma 300 Series Bullet Camera 2. Adjust the camera’s zoom and focus by adjusting the dials at the front of the camera using a screwdriver. On the front (focus) screw, F and N stand for far and near, respectively. On the rear (zoom) screw, T and W stand for wide angle and telephoto.
- Page 12 (RA) number. Contact technical support for an RA number. Copyright ©2015 by SnapAV. All rights reserved. SnapAV, Luma Surveillance, and all related marks and images are trademarks or registered trademarks of SnapAV. Version 150902-1151...
