Luma Surveillance 310 Series Quick Start Manual

Dvr surveillance recorder, web interface
Hide thumbs Also See for 310 Series:

Advertisement

Table of Contents

310 Series
DVR Surveillance Recorder
Web Interface
Quick Start
Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 310 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Luma Surveillance 310 Series

Summary of Contents for Luma Surveillance 310 Series

  • Page 1 310 Series DVR Surveillance Recorder Web Interface Quick Start Guide...
  • Page 2 310 Series DVR Quick Start Guide Read this page before you go to the job site! For maximum control and convenience, your system should be connected to the Internet via a local network router. For installation, you must be able to access this network through a personal computer.

  • Page 3: Table Of Contents

    310 Series DVR Quick Start Guide Contents Contents Safety Tips ......4 Edit Camera Settings (Optional) ..11 Set Up the Hardware .

  • Page 4: Safety Tips

    310 Series DVR Quick Start Guide Safety Tips Safety Tips Handle this device with care. The performance and lifespan of the hard drive is affected by temperature. Use this device in Do not strike or shake this device. temperatures ranging from 14–131 °F.

  • Page 5: Set Up The Hardware

    310 Series DVR Quick Start Guide Set Up the Hardware Set Up the Hardware ß or à AC Power Optional local video monitor LCD Monitor/Flat Panel TV Camera(s) Optional USB Mouse Network Gateway Caution: Do not power up the DVR until these steps are complete.

  • Page 6: Install And Run The Luma Utility

    310 Series DVR Quick Start Guide Install and Run the Luma Utility Install and Run the Luma Utility Use the Luma Utility to locate your surveillance hardware and set up communications. This is a PC-only utility. Visit your product page at SnapAV.com and download the Luma Utility installer from the Support tab.

  • Page 7: Edit The Network Settings

    310 Series DVR Quick Start Guide Edit the Network Settings Edit the Network Settings To change the network settings at a later date, consult the DVR manual. Suggested Best Practices Ensure the Enable DHCP box is activated. In your router, reserve an IP address and assign it to the DVR’s MAC address (found on the recorder’s...
  • Page 8 310 Series DVR Quick Start Guide Prep for Plugin-Free Browsers Prep for Plugin-Free Browsers With the update to firmware v3.5.35 build 201103, Chrome, Safari, and Microsoft Edge can view your system remotely. Port forwarding setup allows you to access the DVR from the internet for remote viewing and other operations.

  • Page 9: Complete Port Forwarding

    310 Series DVR Quick Start Guide Complete Port Forwarding Complete Port Forwarding Port forwarding setup allows you to access the DVR from the internet for remote viewing and other operations. These settings are entered in your network router, typically in a menu called Port Forwarding or Applications and Gaming.

  • Page 10: Start The Web Interface

    310 Series DVR Quick Start Guide Start the Web Interface Start the Web Interface Get the Luma Plug-In Open your browser, type the IP address of the recorder (from page 7) into the address bar, and hit Return. Below the login window, there may be a link that reads, “Please click here to download and install the plug- in.

  • Page 11: Check The Cameras

    310 Series DVR Quick Start Guide Check the Cameras Check the Cameras After log-in, your screen shows the live page, which should look similar to the illustration below. If a camera is out, check its connection to your DVR, and ensure that it is powered up.

  • Page 12: Edit Camera Settings (Optional)

    310 Series DVR Quick Start Guide Edit Camera Settings (Optional) Edit Camera Settings (Optional) To adjust camera settings, click on the settings icon ( ) on the main page. Navigate to Video/Audio > Video to adjust the camera settings like bitrate, resolution, and encoding.

  • Page 13: Set Up Dynamic Dns

    310 Series DVR Quick Start Guide Set Up Dynamic DNS Set Up Dynamic DNS This allows you to connect to your surveillance system from anywhere, via the Internet, using a web address that’s easy to remember. Click on Basic Network Settings > DDNS.

  • Page 14: Create Users And Set Passwords

    310 Series DVR Quick Start Guide Final Setup Final Setup Create Users and Set Passwords Click on User Management. Click the Add button. Enter the new account’s user name and password. Account names can be up to 32 characters long, and can contain numbers and letters only.

  • Page 15: You're Done

    310 Series DVR Quick Start Guide You’re Done! You’re Done! Your system is now operational. Next, customize your system for your customer’s needs. Using the simple web interface, you can: Set protocols for remote computers for when they log in to the surveillance system.

  • Page 16: Support

    310 Series DVR Quick Start Guide Support Support Need Help? Contact Tech Support! If you need further clarification, please email support@SnapAV.com. For more information, instructional videos, support documentation, or ideas, visit our website and view your item’s product page at SnapAV.com.

This manual is also suitable for:

Lum-310-dvr-8ch-0tLum-310-dvr-8ch-1tLum-310-dvr-4ch-1tLum-310-dvr-16ch-2tLum-310-dvr-4ch-0tLum-310-dvr-16ch-0t
