- Page 1 110 Series Mini Turret 1080p Analog Surveillance Camera Quick-Start Guide...
-
Page 2: Box Contents
Luma 110 Series Mini Turret Camera Box Contents Camera Mounting bracket Self-adhesive mounting template 3 x wall anchors with screws 3mm hex wrench You must provide: Phillips screwdriver Power source: 12V DC... - Page 3 Luma 110 Series Mini Turret Camera Inspection Ensure that the device is in good condition and all parts are included. If the product does not work properly, contact technical support. Do not disassemble the camera for repair or maintenance. We recommend installing with RJ59 or RJ6 cabling with two-wire power (regular or siamese).
- Page 4 Luma 110 Series Mini Turret Camera Overview Before installing, familiarize yourself with the parts of your camera. Lens + Infrared Camera Body...
- Page 5 Luma 110 Series Mini Turret Camera Camera Base Cables The camera comes with two cables: the BNC cord for video, and the barrel cord for power.
-
Page 6: Prepare For Installation
Luma 110 Series Mini Turret Camera Prepare for Installation Power off all equipment during installation. Ensure the wall is strong enough to hold three times the weight of the camera and the mount. If the mounting surface is cement, use the included expansion screws to install the camera. - Page 7 Luma 110 Series Mini Turret Camera Locking Hex Screw...
-
Page 8: Install The Camera
Luma 110 Series Mini Turret Camera Install the Camera 1. Attach the base of the camera to the ceiling and secure it with screws. 2. Route the cables through the cable hole. Note that the base provides extra space between the camera and the ceiling for wire management. - Page 9 Luma 110 Series Mini Turret Camera...
-
Page 10: Adjust The Camera
Luma 110 Series Mini Turret Camera Adjust the Camera Manually adjust the camera to get an optimum angle, being careful not to touch the lens. The camera is free-floating for perfect pan and tilt control. To assist in achieving the perfect aim, this camera has an OSD menu that can be accessed through your DVR. - Page 11 Luma 110 Series Mini Turret Camera 0°–360° 0°–75° 0°–360°...
- Page 12 Support 866-838-5052 or TechSupport@SnapAV.com 5-Year Limited Warranty This Luma Surveillance™ product has a 5-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products that have been abused, modified or disassembled.
