Luma Surveillance 710 Series Quick Start Manual

Dome ip surveillance camera
Hide thumbs Also See for 710 Series:
Table of Contents

Advertisement

Quick Links

710 Series Dome
510 Series Dome
IP Surveillance Camera
Quick-Start
Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 710 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Luma Surveillance 710 Series

Summary of Contents for Luma Surveillance 710 Series

  • Page 1 710 Series Dome 510 Series Dome IP Surveillance Camera Quick-Start Guide...

  • Page 2: Box Contents

    Plastic “needle” for cables You must provide: A network connection (and an NVR, if desired) with admin rights to the network Mobile device with Luma Surveillance mobile app (recommended) or CCTV tester Power source: PoE or 12V DC Phillips screwdriver WARNING: This product can expose you to chemicals including cadmium, which is known to the State of California to cause cancer.
  • Page 3 This allows you to use OvrC, a powerful remote maintenance tool (see OvrC.com) and lets you use the Luma Surveillance mobile app to check on the camera from anywhere. For installation using this guide, you must be able to access this camera through a personal computer.

  • Page 4: Safety Tips

    Luma 510/710 Series Dome Camera Safety Tips Handle this device with care. Do not strike or shake this device. Protect the power cord from being stepped on or pinched, particularly where it connects to the device and the power outlet.

  • Page 5: Your Camera

    Luma 510/710 Series Dome Camera Your Camera Before installing, familiarize yourself with the parts of your camera. Waterproof Camera Lens and Housing Body IR emitters (top) Dome Cover Taillless Connector Camera Body Mounting (bottom) Plate...
  • Page 6 Luma 510/710 Series Dome Camera Your Camera’s Utility Port Reset Button SD Card Slot...
  • Page 7 Luma 510/710 Series Dome Camera Preserving Your Camera Foam Ring CAUTION: Do not throw away the foam ring around the camera lens! It protects the camera from glare from its infrared lights. Dome Tether and Base Tether We recommend you do not remove the security tether that holds the dome cover to the camera base.
  • Page 8 Luma 510/710 Series Dome Camera Installation with an NVR If you are installing with an NVR, follow these instructions. Otherwise, follow the instructions starting on the next page. 1. Ensure your NVR has the latest firmware. If it does not, your NVR may be unable to locate and activate your camera.
  • Page 9 Connect the camera to your PC and run the Luma Utility. It searches for attached Luma Surveillance devices. If your camera does not appear, check the connection, ensure the camera is powered up, then click the Refresh button.

  • Page 10: Activate The Camera

    Luma 510/710 Series Dome Camera Activate the Camera Click on the entry for your camera to view its details. If the camera is inactive, use the text boxes at the lower right of the Luma utility window to activate the camera by creating a new secure password.

  • Page 11: Physical Installation

    Luma 510/710 Series Dome Camera Physical Installation 1. Drill pilot holes for your screws in the mounting surface, using the supplied template. 2. Attach the mounting plate and run the cables through it. 3. Thread the cables through the waterproof housing as shown below left and below right.
  • Page 12 Luma 510/710 Series Dome Camera 5. Connect all cabling to the camera. You can use the lanyard on the camera base to hang the camera on the hook inside the waterproof housing. 6. Place the supplied silica pack inside the waterproof housing.
  • Page 13 Luma 510/710 Series Dome Camera Start the Web Interface Open your browser and navigate to the camera’s IP address. Below the login area, you may see: “Please click here to download and install the plug-in. Close the browser when installing the plug-in.”...
  • Page 14 Luma 510/710 Series Dome Camera Check the Camera After logging in, your screen shows the live page, similar to the illustration at left. If it does not appear, check the connection to your NVR or network, and ensure that the camera is powered up.
  • Page 15 Luma 510/710 Series Dome Camera Additional Setup Best Practices Be sure to complete customization of the camera using the NVR’s web interface: Set up DDNS Add additional users Calibrate the time settings Set up recording schedule Enable motion detection See your NVR’s manual for full details.
  • Page 16 3-Year Limited Warranty This Luma Surveillance™ product has a 3-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use.

This manual is also suitable for:

510 series
