  • Page 1 Operator’s Manual WristOx Wrist Oximeter English...
  • Page 3 References to “Respironics” in this manual imply Respironics, Inc. Respironics is a registered trademark of Respironics, Inc. References to “NONIN” in this manual imply Nonin Medical, Inc. Nonin is a registered trademark of Nonin Medical, Inc. WristOx™ is a trademark of Nonin Medical, Inc. ©2004 Respironics...

  • Page 5: Guide To Symbols

    Guide to Symbols Detailed information for functional symbols can be found in “Using the WristOx.” Symbol Description Attention: See Instructions for Use or related materials. Type BF Applied Part (Patient isolation from electrical shock). UL Mark for Canada and the United States with respect to electric shock, fire, and mechanical hazards only in accordance with UL 2601-1 and CAN/CSA C22.1 No.
  • Page 6 Detailed information for functional symbols can be found in “Using the WristOx.” Symbol Description Serial Number...

  • Page 7: Precautions For Use

    Warnings • Read this entire manual carefully before using the WristOx. • The WristOx is intended only as an adjunct in patient assessment. It must be used in con- junction with other methods of assessing clinical signs and symptoms. • General operation of the WristOx might be affected by the presence of an electrosurgical...
  • Page 8 • As with all medical equipment, carefully route patient cables and connections to reduce the possibility of patient entanglement or strangulation. • Use the WristOx only within the specified temperature ranges: +32°F to +122°F (0°C to 50°C) for operating, and 14°F to 122°F (-10°C to +50°C) for storage and transportation.
  • Page 9 • U.S. federal law restricts this device to sale by or on the order of a physician. • Before using any sensor, carefully read the Directions for Use. • Do not, under any circumstances, perform any testing or maintenance on the WristOx while it is being used to monitor a patient.
  • Page 10 • If the WristOx fails to respond as described, refer to “Troubleshooting” or discontinue use until the situation has been corrected by qualified personnel.
  • Page 11 • The WristOx is designed to determine the percentage of arterial oxygen saturation of func- tional hemoglobin. Significant levels of dysfunctional hemoglobin may affect the accuracy of the measurement. • The WristOx might misinterpret motion as good pulse quality. Minimize patient motion as much as possible, or change the type of sensor being used.
  • Page 12 Unpacking and Inspecting the WristOx Contact the carrier immediately if the shipping carton for the WristOx is damaged. Confirm that the items listed below are packed with the WristOx: • WristOx™ Wrist Oximeter • Two 1.5V Alkaline N-cell Batteries • WristOx Operator’s Manual •...

  • Page 13: Indications For Use

    Do not use the WristOx when alarms are required! The WristOx comes packaged in Spot Check mode. In Spot Check mode, inserting a finger in the sensor turns on the WristOx automatically, and removing a finger turns off the WristOx automatically.

  • Page 14: Installing The Batteries

    Installing the Batteries Use your thumb to loosen the lower front cover of the WristOx, and carefully remove the battery door by sliding it downward.
  • Page 15 Carefully re-position the battery door. Do not force the door into place; it fits only when positioned properly. If the WristOx does not turn on when a sensor is plugged into the unit, reinsert the batteries or refer to “Troubleshooting.”...

  • Page 16: Important Notes About Battery Use

    Important Notes About Battery Use The Battery Indicator will begin to flash approximately 30 minutes before entering critical battery mode. In critical battery mode, the WristOx no longer monitors or records patient data. Replace low batteries as soon as possible.
  • Page 17 The WristOx performs an automatic startup (initialization) sequence and self-test when a sensor is plugged in. Verify that all indicators display during the first phase of the startup sequence. If any indicator is not displayed, do not use the WristOx. Contact Respironics Customer Service for assistance.

  • Page 18: Attaching The Sensor

    Place the patient’s finger inside the sensor. Refer to the respective sensor instructions for specific information about placement and patient safety. Plug the sensor into the connector at the top of the WristOx, ensuring that all indicators appear during the first phase of the startup sequence.

  • Page 20: System Features

    (indicated by the %SpO icon). Pulse Rate Display The pulse rate display is the lower numeric display on the left side of the WristOx (identified by the symbol). This 3-digit indicator display shows the pulse rate in beats per...

  • Page 21: Pulse Quality Indicator

    Pulse Oximeter Sensor Indicator The Pulse Oximeter Sensor Indicator indicates when a sensor has become disconnected, has failed, or has not been applied correctly. Pulse Strength Bargraph Indicator This 10-segment bargraph indicates pulse strength as determined by the oximeter. The height of the Pulse Strength Bargraph is proportional to the pulse amplitude.

  • Page 22: Battery Indicator

    Battery Indicator Any time the WristOx batteries are low or critical, this Indicator blinks, providing early warning to replace the batteries. After critical battery capacity is met, the display turns off and monitoring is stopped. Numeric Indicators Numeric Indicators appear after an %SpO or pulse rate reading is complete, providing results of the measurement.

  • Page 23: Accessing Advanced Features

    Respironics pulse oximeter models. NOTE: Data is stored in the WristOx regardless of which mode the device is in.
  • Page 24 In addition, information about device model number, revision, and parameters can be retrieved; patient data can be downloaded and stored; WristOx memory can be cleared; and the WristOx date and time can be synchronized to the date and time of the computer.
  • Page 25 %SpO and pulse rate data might add to patient anxiety in longer-term studies. In Partial Display mode, %SpO and pulse rate data are not displayed on the WristOx, but the Pulse Strength Bargraph is still visible.

  • Page 26: Activation Options

    Spot Check mode is the WristOx default activation setting. In Spot Check mode, inserting a finger in the sensor turns ON the WristOx automatically, and removing a finger turns OFF the WristOx automatically. In this mode, the sensor can be left attached (plugged in) to the WristOx.

  • Page 27: Sensor Activation Mode

    Sensor Activation mode can be selected with nVISION software (version 5.0 or greater). In this mode, connecting and disconnecting the sensor from the WristOx functions like an ON/ OFF switch (whether or not a finger is in the sensor). In Sensor Activation mode, the WristOx shuts off automatically after 30 minutes of no use or invalid pulse detection.
  • Page 28 Use the instructions below to connect the WristOx to a computer: Connect the cable to the appropriate COM port on the computer. Plug the cable to the top of the WristOx. Wait until CP appears in the WristOx display. The WristOx is now ready for use with nVISION software.

  • Page 29: Memory Features

    Only recording sessions longer than one minute are stored. Each time the WristOx is turned on, the current oximeter time and date (if the clock is set properly) are stored in memory to allow quick differentiation of recording sessions. Patient and pulse rate are stored every four seconds (default), or every one or two seconds if programmed using nVISION software (version 5.0 or greater).
  • Page 30 NOTE: Storage rates do not affect battery life; however, data storage capacity is reduced when using a 1- or 2-second storage rate. Using a 2-second storage rate, data storage capacity is reduced to approximately 16 hours. Using a 1-second storage rate, data storage capacity is reduced to approximately 8 hours. The stored pulse rate ranges from 18 to 300 pulses per minute.
  • Page 31 Clean the WristOx with a soft cloth dampened with isopropyl alcohol. Do not pour or spray any liquids onto the WristOx, and do not allow any liquid to enter any openings in the device. Allow the WristOx to dry thoroughly before reusing.

  • Page 32: Specifications

    Specifications OXIMETER SPECIFICATIONS Oxygen Saturation Range (%SpO 0% to 100% Pulse Rate Range 18 to 300 pulses per minute Displays Numeric Displays 3-digit Indicators Pulse Indicator Pulse Strength Bargraph Accuracy Blood Oxygen Saturation 70% to 100% ± 2 digits (%SpO ) (±...
  • Page 33 Measurement Wavelengths and Output Power 660 nanometers @ 3 mw nominal Infrared 910 nanometers @ 3 mw nominal Altitude Operating Altitude Up to 40,000 feet Hyperbaric Pressure Up to 4 atmospheres SYSTEM SPECIFICATIONS Temperature Operating +32° to +122°F (+0° to +50°C) Storage/Transportation 14°...
  • Page 34 Humidity Operating 10% to 90% noncondensing Storage/Transportation 10% to 95% noncondensing Power Requirements Two 1.5V alkaline N-cell batteries Battery Life Operating minimum 24 hours of continuous operation Storage 9 months Dimensions (without sensor or strap) 2 in H x 1.75 in W x 0.75 in D (5.08 cm H x 4.445 cm W x 1.905 cm D) Weight ~0.88 oz.
  • Page 35 Memory Type Nonvolatile Capacity 33 hours @ 4 sec. data storage rate; 16 hours @ 2 sec. rate; 8 hours @ 1 sec. rate CLASSIFICATIONS PER IEC 60601- 1 / CSA601.1 / UL2601-1 Type of Protection Internally powered (on battery power) Degree of Protection Type BF-Applied Part Mode of Operation...

  • Page 36: Parts And Accessories

    Parts and Accessories 1019439 WristOx Travel Pack 1019488 WristOx User Manual 1019444 Oximeter Sensor Adapter 1019443 Oximeter Serial Cable Pulse Oximeter Reusable Sensors 1019437 Adult Flex Sensor 1019522 WristOx Finger Clip Sensor...
  • Page 37 (version 5.0 or greater) for Microsoft Windows ® 95/98/00/NT 1019521 Sensor Attachment Tape, 100 per box 1019440 Wristband (10 pack) 1019438 Wristband Extender (10 pack) 1019448 WristOx 1.5v Alkaline Batteries (24 pack) For more information about parts and accessories, contact Respironics at 800-345-6443.

  • Page 38: Service And Support

    Thus, there are no critical parts to drift, and no calibration of the pulse oximeter module is required. For information about the WristOx and accessories, contact your local distributor or Respironics Customer Service at (800) 345-6443.

  • Page 39: Warranty

    This warranty shall be the sole and exclusive remedy by the purchaser hereunder for any WristOx delivered to the purchaser that is found to be defective in any manner, whether such remedies be in contract, tort, or by law.
  • Page 40 Respironics personnel only. Accordingly, any sign or evidence of opening the WristOx, field service by non-Respironics personnel, tampering, or any kind of misuse of the WristOx shall void the warranty. All non-warranty work shall be done according to Respironics standard rates and charges in effect at the time of delivery to Respironics.

  • Page 41: Troubleshooting

    Sensor is disconnected. Re-connect sensor and try again. WristOx set in Programmed Use nVISION software to reset mode. WristOx in Spot Check or Sensor Activation mode. No %SpO or pulse WristOx set in Partial Dis- Use nVISION software to reset play mode.
  • Page 42 Problem Possible Cause Possible Solution No pulse display on Low patient pulse strength. Reposition or replace finger; keep bargraph. sensor motionless. Remove and re-connect sensor. Sensor applied incorrectly. Refer to sensor instructions to apply sensor correctly. Poorly perfused finger. Reposition or replace finger; keep sensor motionless.
  • Page 43 Problem Possible Cause Possible Solution No pulse display on Possible interference from: Reduce or eliminate interference. bargraph, cont’d. • arterial catheter • blood pressure cuff • electrosurgical procedure • infusion line Reduced circulation from Allow hand to rest without squeez- excess pressure on sensor.
  • Page 44 Call Respironics Customer Service. insertion area. Excessive patient motion. Reduce patient motion. Pulse Oximeter Sen- Poor signal detected from Reposition or replace finger; keep sor indicator appears. finger. sensor motionless. Warm the application site. The WristOx needs repair. Call Respironics Customer Service.
  • Page 45 WristOx date and time set- Use nVISION software to set date tings are incorrect (or lost and time correctly. after removing batteries). If these solutions do not correct the problem, please contact Respironics Customer Service at 800-345-6443. 4640-000-01 1019488...
  • Page 46 Manufactured by Nonin Medical, Inc. for Respironics, Murrysville.
