Remote Control Systems EVO-BATT Instruction Manual

P.O Box 578 Casino, NSW, 2470 Australia
Phone: International ++614 2902 9083
Australia (04) 2902 9083
Website: http://rcs-rc.com
E mail: info@rcs-rc.com
EVO-BATT
Digital Proportional R/C
THESE INSTRUCTIONS REFER SPECIFICALLY TO THE
They should be read in conjunction with the RCS RX & ESC you are using.
THE EVO-BATT CAN ONLY BE USED WITH
THE SPEED – DIRECTION KNOB HAS
150°.CONTROL EITHER SIDE OF NEUTRAL
1 X FULL THROW SERVO FOR WHISTLE.
When used for battery R/C you will supply a locomotive or trail car, the 14 – 20-volt traction batteries (depending on ESC), a fuse,
ON-OFF switch and wires where necessary, to connect the ESC to the battery and motor(s).
Where soldering is necessary, we recommend a low wattage soldering iron and resin core solder.
TO AVOID CONFUSION WITH OTHER OPERATORS, WE SUGGEST YOU MARK THE TX TO SHOW WHICH LOCO IT IS OPERATING.
DO NOT ATTEMPT TO ALTER THE TUNING OF THE RADIO EQUIPMENT.
DO NOT USE RADIO CONTROL EQUIPMENT IN THUNDERSTORMS.
CHILDREN UNDER 12:
RCS TX & RX PRODUCTS MUST NOT BE USED FOR CONTROLLING RIDE ON LOCOMOTIVES CAPABLE OF
Thank you for purchasing this DSM2 3 channel Tx handpiece.
INSTRUCTION MANUAL
REMOVE REAR OF EVO-BATT TO INSERT
THE 9 VOLT BATTERY.
LED BLINKS WHEN BATTERY LOW.
A HIGH QUALITY 9V SNAP IS USED.
CAN ONLY BE USED WITH "CENTRE OFF" ESC's.
THE EVO-BATT IS GUARANTEED FOR ONE YEAR.
CAUTION
ADULT SUPERVISION RECOMMENDED DURING USE.
CARRYING MEMBERS OF THE GENERAL PUBLIC.
TABLE OF CONTENTS
PROVIDED IN INSTRUCTIONS.
Page # 1 Introduction.
Page # 2 Preparing the EVO-BATT. Binding.
Page # 3 Using with Centre off battery R/C ESC.
Page # 4 Wiring # VIPER ESC.
Other instructions for use with battery R/C are
found with the ESC.
http://www.rcs-rc.com/pages/instructions
DELTANG R/C BASED EVO-BATT HANDPIECE.
"CENTRE OFF" BATTERY R/C ESC's.
THE TWO FUNCTION TRIGGERS USE
THE CH # 5 BIND BUTTON CAN ALSO
BE USED FOR A 3
CHANNEL # 3 ON THE RX.
RD
TRIGGER.
!!
