KUKA.VisionTech 2.1
4.2

KUKA GigE switch

Basic data
Ethernet interface
Ambient condi-
tions
Standards and
guidelines
20 / 109
Name
EN 61000-6-2
EN 61000-6-4
Housing
Protection classifica-
tion
Dimensions
Weight
Control voltage
Energy consumption
MTBF
Conformity
Interface
Standard
Ports
Packet size
Auto-functions
PoE
Protective function
Power infeed
Storage
Operation
Air humidity
Name
2004/108/EC
EN 55022
Definition
Electromagnetic compatibility (EMC) - Part 6-2:
Generic standards – Immunity for industrial envi-
ronments
Electromagnetic compatibility (EMC) - Part 6-4:
Generic standards – Emission standard for
industrial environments
Metal
IP 30
41 x 99.9 x 144.3 mm
580 g
12 ... 36 V DC
approx. 7.5 W
> 450000 h @ 45°
CE, FCC Part 15, RoHS
1000base-T, 100base-TX, 10base-T
IEEE 802.3 for 10base-T
IEEE 802.3u for 100base-TX and 100base-X
IEEE 802.3z for 1000base-X
IEEE 802.3ab for 1000base-T
IEEE 802.3x for flow control
IEEE 802.3at PoE specification (up to 30 watts
per port for PoE)
4x with PoE, 1x SFP, 1x without PoE
Up to 9 kB, supports jumbo frames
Auto-negotiation, auto-crossover
Conforms to IEEE 802.3at
Against overload current
Up to 30 watts per port
-40 °C to +85 °C (233 K to 358 K)
-40 °C to +60 °C (233 K to 333 K)
5 ... 95% (no condensation)
Definition
EMC Directive:
Directive 2004/108/EC of the European Parlia-
ment and of the Council of 15 December 2004
on the approximation of the laws of the Member
States relating to electromagnetic compatibility
and repealing Directive 89/336/EEC
Information technology equipment – Radio dis-
turbance characteristics – Limits and methods of
measurement
Issued: 11.10.2013 Version: KST VisionTech 2.1 V1
