Axxess AX-FD-SSO Installation Instructions
Axxess AX-FD-SSO Installation Instructions

Axxess AX-FD-SSO Installation Instructions

Ford stop/start override interface 2015-up

Advertisement

INTRODUCTION
The AX-FD-SSO is designed to disengage the STOP/START feature of the vehicle, and keep that feature disengaged even after the key has been
cycled. The AX-FD-SSO will work with either an aftermarket radio, or a factory radio. A simple plug n' play installation is all that is required to install
the device in the vehicle, and programming through a Windows 10 computer via the
APPLICATIONS
Ford
Edge
2015-up
Escape
2017-up
F-150
2015-up
AxxessInterfaces.com
Ford Stop/Start Override Interface
2015-up
INTERFACE FEATURES
• Allows the override of the STOP/START engine feature
• The factory STOP/START button can resume the STOP/START feature
• Can be used with either a factory or aftermarket radio
• Vehicle type configured through the Axxess Updater software program
• Simple plug n' play installation, no wiring required
Axxess Updater
Focus
2016-up
Fusion
2015-up
© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
software program.
AX-FD-SSO
I N S T A L L A T I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Programming .........................................................2
Connections ............................................................3
Operation ................................................................4
INTERFACE COMPONENTS
• AX-FD-SSO interface
• AX-FD-SSO harness (qty. 2)
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Zip ties • Cutters (for zip ties)
• Micro-B USB cable
(Axxess part number USB-MINI-CAB)
Product Info
REV. 7/26/19 INSTAX-FD-SSO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AX-FD-SSO and is the answer not in the manual?

Questions and answers

Summary of Contents for Axxess AX-FD-SSO

  • Page 1 The AX-FD-SSO is designed to disengage the STOP/START feature of the vehicle, and keep that feature disengaged even after the key has been (Axxess part number USB-MINI-CAB) cycled. The AX-FD-SSO will work with either an aftermarket radio, or a factory radio. A simple plug n’ play installation is all that is required to install Axxess Updater the device in the vehicle, and programming through a Windows 10 computer via the software program.
  • Page 2 When the Configuration Successful box pops up, the programming Connect the micro-B USB cable (sold separately) to the computer and AX-FD-SSO interface. Open the Axxess Updater software program and process is complete. (Figure C) wait until the word Ready is shown in the bottom left of the screen.
  • Page 3 1. Unplug the connector behind the climate control. 5. Zip tie the harness securely under the dash to avoid it from coming down. 2. Plug the AX-FD-SSO harness in between the climate control and climate control harness. 3. Plug the AX-FD-SSO harness into the AX-FD-SSO interface.
  • Page 4 AX-FD-SSO I N S T A L L A T I O N I N S T R U C T I O N S Having difficulties? We’re here to help. OPERATION Contact our Tech Support line at: 1-800-253-TECH Re-engaging the STOP/START feature Or via email at: techsupport@metra-autosound.com...
