Predator Sync Configuration Instructions
1. Set ID#
a. Identify which pattern and sequence you want and look up ID#s on table.
b. Connections
i.
RED: +10-30Vdc
ii. WHT: +10-30Vdc (Note: you will need to disconnect after power is applied)
iii. BLK: Ground
c. Apply power to unit
d. Without disconnecting power from unit, disconnect WHT wire
e. Momentarily connect WHT to Ground to change ID #
i.
Identify ID# by number of sequential flashes
ii. Possible ID#s: 1 – 4
f. Disconnect power from unit to get out of ID mode.
2. Set Pattern
a. Reapply power to units.
b. Once all Light Head ID#s are configured, make sure all lights are flashing the same
pattern
c. Connect corresponding colored wires of all units together: RED to RED, etc.
d. Change Pattern
i.
Momentarily connect WHT wires to Ground
ii. Observe pattern change on all lights connected
e. Insulate all wires by taping with electrical tape
3. Connect Master Switch for Application
a. IMPORTANT! Ensure WHT Pattern/Sync Wires are tied together
1 LIGHT
Single Light Operation: Follow the ID Selection steps and set the PREDATOR II to ID#1 if it is
not already. NOTE: Steady Burn is produced for patterns 9 & 10 in Single Operation.
2 LIGHTS
ALTERNATING: To obtain Alternating patterns, follow the ID SELECTION steps and set one PREDATOR II to ID#1 and the other to ID#3.
Then proceed to the PATTERN SELECTION steps.
SIMULTANEOUS: To obtain Simultaneous patterns, follow the ID SELECTION steps and set both PREDATOR II lights to ID#1. Then
proceed to PATTERN SELECTION steps.
4 LIGHTS
X-Pattern: To obtain X-patterns, follow the ID SELECTION steps and set one of the four PREDATOR II lights to ID#1, one to ID#2, one to
ID#3, and one to ID#4. Then proceed to PATTERN SELECTION steps. NOTE: Be sure to mount each PREDATOR II in the correct
placement based on ID#.
SINGLE SURFACE MOUNT
WARNING SYSTEM
Flash Pattern and ID# Setup
X-Pattern Sequence
ID#1 > ID#4 > ID#2 > ID#3
X-Pattern Light Head Placement
ID#4
ID#2
ID#3
ID#1
FLASH PATTERNS for
SINGLE SURFACE MOUNT PREDATOR II
# Pattern Name
1 Light
Alternating
Simultaneous
X-Pattern
2 Lights
2 Lights
4 Lights
1
Quint
X
X
X
2
Warp
X
X
X
3
Inter-Cycle
X
X
Flash
4
Double Flash
X
X
X
5
Quad Flash
X
X
X
6
Power Pulse
X
X
X
7
Road Runner
X
X
X
8
Q-Switch
X
X
9
Road Runner
X
X
Steady Burn
10
Quad
X
X
Steady Burn
11
E-Ideal
X
X
X
Single Flash
12
E-Ideal
X
X
X
Double Flash
13
Quad2 Flash
X
X
X
14
Double2 Flash
X
X
X
15
X-Warp
16
X-Double
17
PowerRunner
X
X
X
18
LCR Quint
X
X
X
19
Warp³
X
X
X
20
Ultra Warp
X
X
X
21
Thunder and
X
X
Lightning
22
LiteSpeed
X
X
X
23
SuperSonic
X
X
24
LCR LiteSpeed
X
X
X
25
SuperSonic
X
X
X
Ultra
26
TempoShift
X
X
X
27
TempoShift
X
X
X
Warp
28
SBE2
X
X
X
29
X
X
X
30
X
X
X
31
UltraGlow
X
X
X
32
Cyclone
X
X
X
33
Chameleon
X
X
X
Flashes/
Minute
70
350
70
80
180
113
113
80
200
146
67
95
X
X
545
85
170
67
200
176
EP2SSMDBx 2.09
