2.2

Technical Data

Form 2
Printer
Shipping 18 × 1 8 × 2 7 in
Dimensions (46 × 4 6 × 6 8 cm)
Shipping 44 lbs
Weight (20 kg)
Product 28.5 lbs
Weight (13 kg)
Power Requirements 100–240 V
1.5 A 50/60 Hz
65 W
Sound Emission Does not exceed 70 dB(A).
Radiation Information The Form 2 is a Class 1 Laser product. Accessible radiation is within
Class 1 limits.
Ethernet Connectivity RJ-45 Ethernet (10BASE-T/100BASE-TX) LAN Port
Use a shielded CAT-5 Ethernet cable (not included).
Wi-Fi Connectivity Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz, does not support 5 GHz
Supported security: WEP, WPA
See 9. Technical Specifications for additional specifications.
4
Form 2 Resin Form 2
Finish Kit Cartridge Resin Tank
8 × 9 × 9 in 9.5 × 8 × 3 in 11.25 × 1 1 × 3 in
(46 × 2 3 × 2 3 cm) (24 × 2 0 × 8 cm) (29 × 2 8 × 8 cm)
6.6 lbs 3.3 lbs 1.8 lbs
(3 kg) (1.5 kg) (0.85 kg)
5.7 lbs 3-3.5 lbs 1.4 lb
(2.6 kg) (1.35-1.6 kg) (0.65 kg)
2.3
Form 2 Build
Platform
7 × 6 .75 × 3 in
(18 × 1 7 × 8 cm)
1.5 lbs
(0.67 kg)
1.4 lb
(0.65 kg)
2.4

Product Elements

1. Cartridge
2. Cover
3. Build Platform
4. Resin Tank
5. Wiper
6. Touchscreen
7. Button
8. Leveling Tool
See 11. Glossary for full
product terminology

Understanding the Touchscreen

The Form 2 display includes a touchscreen and button.
The LCD touchscreen displays print information, settings, and error messages.
It serves as the user interface for the Form 2.
The push button starts and pauses prints when prompted by the touchscreen. Hold
the button to wake and sleep the printer. A light surrounding the button flashes
when the printer is ready to start a print. Press the button to start or stop a print.
Introduction | 5
