4.4.1 To connect with USB :
Use the included USB cable for connecting a computer directly to the printer.
1. Plug one end of the USB cable into the back of the Form 2.
2. Connect the other end to a computer's USB port.
4.4.2 To connect with Ethernet :
The rear of the unit is equipped with a RJ-45 Ethernet (10BASE-T/100BASE-TX)
LAN Port. Use a shielded CAT-5 Ethernet cable (not included) to connect the
printer to a local network.
1. Plug one end of the Ethernet cable into the back of the Form 2.
2. Connect the other end to your LAN.
4.4.3 To connect with Wi-Fi:
The Form 2's built-in Wi-Fi (IEEE 802.11 b/g/n) supports WEP and WPA securi-
ty. Use the Form 2's touchscreen to configure a wireless network connection.
The Form 2's Wi-Fi feature does not support 5 GHz connections.
1. To connect to Wi-Fi, touch Wi-Fi on the settings tab on the touchscreen.
2. Select the name of the network you would like to connect to.
3. Enter the password for that Wi-Fi network using the onscreen keyboard.
4.4.4 To connect with Wi-Fi using a manual IP configuration:
When connected to an active Ethernet connection or available Wi-Fi network,
the Form 2 can be configured with a static IP address.
1. With an established Ethernet or available Wi-Fi connection, open the printer's
Settings menu on the touchscreen.
2. For Wi-Fi networks, select Wi-Fi, then the desired wireless network.
3. For Ethernet connections, simply open Ethernet from the Settings menu.
4. Toggle the Manual IP settings to ON.
5. Input the appropriate IP Address, Subnet Mask, Default Gateway, and Name Server.
12
4.5

Transporting the Form 2

Refer to the Technical Specifications for product weight and dimensions. Keep the pack-
aging for transportation or shipping. The printer's complete packaging kit consists of:
• 1 outer cardboard carton
• 4 foam bottom corner inserts
• 1 foam upper insert, which holds the small accessory boxes
• 1 cardboard lift tray
• 1 protective plastic bag
• Plastic wrap
Original packaging is required for warranty service. Do not ship with resin
inside the printer. Resin left inside the Form 2 can damage the printer in
NOTICE
transit, which may lead to additional fees or void the warranty.
4.5.1 To prepare to transport the Form 2:
1. Always remove the build platform, resin tank, and cartridge before moving or
packaging the Form 2 printer.
2. Wipe residual resin from the build platform and store the platform away
from sunlight.
3. Store the resin tank on a smooth clean surface with the wiper and lid installed.
Protect the tank window on the underside from being scratched, smudged,
or touched. When storing a resin tank in the original box, use a paper towel
to protect the tank window.
4. Store the cartridge with the vent cap closed and the valve cover installed.
When shipping a printer to Formlabs for service, the build platform, resin
tank, power and USB cables, and other accessories should not be shipped
NOTICE
and will not be returned after service. The printer's original packaging is
required for warranty service. Contact other authorized resellers for unique
guidance on shipping requirements.
4.5.2 To package the Form 2:
1. If the printer's outer cardboard carton has been collapsed, start by reassembling
and securely taping the box's bottom opening.
2. Insert all four foam corners, one each, into the internal corners of the card-
board lift tray.
3. Tape the inside of the printer's tank carrier (which holds the resin tank) with
two pieces of painter's tape.
a. Use tape that will not leave residue on the printer's shell.
Preparation and Set Up | 13
