Smith & Noble Metro Track Flat Aluminum Hardware Installation Instructions Manual

Wall mount corner single rod set
Hide thumbs Also See for Metro Track Flat Aluminum Hardware:
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Warranty Service
The enjoyment of your hardware should be everlasting, which is why our products
come with a limited lifetime warranty. The warranty applies to the original owner,
requires a proof of purchase (hang on to your receipt!) and covers defects in material
or craftsmanship. Hardware must have been properly installed. We reserve the right to
determine if your hardware warrants a repair or a replacement. Visit smithandnoble.
com/guarantee to see full details. In need of warranty service? Call us at 800.248.8888
and we'll arrange for a repair or replacement ASAP.
© 2019 Smith & Noble Home, Inc. All Rights Reserved
STEP BY STEP INSTALLATION INSTRUCTIONS
Metro Track
Flat Aluminum
Hardware
SN0419
Wall Mount
Corner Single Rod Set

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Metro Track Flat Aluminum Hardware and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smith & Noble Metro Track Flat Aluminum Hardware

Summary of Contents for Smith & Noble Metro Track Flat Aluminum Hardware

  • Page 1 STEP BY STEP INSTALLATION INSTRUCTIONS Metro Track Flat Aluminum Hardware Warranty Service The enjoyment of your hardware should be everlasting, which is why our products come with a limited lifetime warranty. The warranty applies to the original owner, requires a proof of purchase (hang on to your receipt!) and covers defects in material or craftsmanship.

  • Page 2: Table Of Contents

    Everything Table of Contents You Need Getting Started ........3 Step 1 - Wall Mount Corner Single Rod Set .

  • Page 3: Step 1 - Getting Started

    STEP 1 - GETTING STARTED OVERVIEW Getting Started Wall Mount Corner Single Rod Set Before you begin, check the accompanying diagram to make sure you have all the parts you need. You’ll need to make sure the surface you intend to install your hardware is sturdy Regular Corner enough to accommodate the brackets.
  • Page 4 STEP 2 - MOUNTING BRACKETS STEP 2 - MOUNTING BRACKETS Mounting the Brackets Figure A Place the panel on the rod. To ensure Place center of bracket cover plate it drapes at the correct length, hold level against wall at the marked spots. it up to the spot you wish to install Using a pencil, lightly draw a circle it;...

  • Page 5: Step 3 - Attaching The Rod Connector

    STEP 3 - ATTACHING THE ROD CONNECTOR STEP 4 - PLACING CARRIERS & END STOPS Adding or Removing Carriers to the Rod Depending on your order, you may have CARRIERS Your track rod will come with all master ROD CONNECTOR received a rod connector.

  • Page 6: Step 5 - Attaching Brackets To Rod

    STEP 7 - ATTACHING CORNER BRACKETS STEP 5 - ATTACHING BRACKETS TO ROD MOUNTING POST CHANNEL Insert the mounting posts into the Corner or Elbow Bracket ° MOUNTING channel in the back of the track. BRACKET Do not tighten at this time. Slide in 90°...

  • Page 7: Step 8 - Attaching Bracket Posts To Bracket Bases

    STEP 8 - ATTACHING BRACKET POSTS TO BRACKET BASES STEP 9 - ATTACHING DRAPERY TO ROD Insert drapery pin hooks into carriers Align the mounting posts in the back of and master carriers. the track with the brackets mounted to MOUNTING the wall.

  • Page 8: Care & Cleaning

    CARE & CLEANING ACCESSORIES Baton/Wand (optional) Minimal care and cleaning is needed to maintain the beauty of your Hardware. Baton/Wand will be pre-attached to the CLIP To Vacuum: Use brush or dust head attachment. master carrier(s). To Dust: Use soft, clean cloth. BATON/ WAND smithandnoble.com...
