Smith & Noble Metro Track Flat Wood Hardware Installation Instructions Manual

Ceiling mount single return rod set
Hide thumbs Also See for Metro Track Flat Wood Hardware:
Table of Contents

Advertisement

Quick Links

Download this manual
Warranty Service
The enjoyment of your hardware should be everlasting, which is why our products
come with a limited lifetime warranty. The warranty applies to the original owner,
requires a proof of purchase (hang on to your receipt!) and covers defects in material
or craftsmanship. Hardware must have been properly installed. We reserve the right to
determine if your hardware warrants a repair or a replacement. Visit smithandnoble.
com/guarantee to see full details. In need of warranty service? Call us at 800.248.8888
and we'll arrange for a repair or replacement ASAP.
© 2019 Smith & Noble Home, Inc. All Rights Reserved
STEP BY STEP INSTALLATION INSTRUCTIONS
Metro Track
Flat Wood
Hardware
SN0519
Ceiling Mount
Single Return Rod Set

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Metro Track Flat Wood Hardware and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smith & Noble Metro Track Flat Wood Hardware

Summary of Contents for Smith & Noble Metro Track Flat Wood Hardware

  • Page 1 STEP BY STEP INSTALLATION INSTRUCTIONS Metro Track Flat Wood Hardware Warranty Service The enjoyment of your hardware should be everlasting, which is why our products come with a limited lifetime warranty. The warranty applies to the original owner, requires a proof of purchase (hang on to your receipt!) and covers defects in material or craftsmanship.

  • Page 2: Table Of Contents

    Everything Table of Contents You Need Getting Started ........3 Step 1 - Ceiling Mount Return Rod Set .

  • Page 3: Step 1 - Getting Started

    STEP 1 - GETTING STARTED OVERVIEW Getting Started Ceiling Mount Single Return Rod Before you begin, check the accompanying diagram to make sure you have all the parts you need. You’ll need to make sure the surface you intend to install your hardware is sturdy enough to accommodate the brackets.

  • Page 4: Step 2 - Marking The Bracket Placement

    STEP 2 - MARKING BRACKET PLACEMENT STEP 3 - ATTACHING THE ROD CONNECTOR Mounting the Brackets Depending on your order, you may have received a rod connector. Place the panel on the rod. Hold it up ROD CONNECTOR to the spot you wish to install it mak- A rod connector is the short piece ing sure there is enough spacing from of metal placed inside each end of...

  • Page 5: Step 5 - Attaching Brackets To Rod

    STEP 4 - PLACING CARRIERS & END STOPS STEP 5 - ATTACHING BRACKETS TO ROD Adding or Removing Carriers Insert the mounting posts into the CEILING CHANNEL BRACKET to the Rod channel in the back of the track. CARRIERS Do not tighten at this time. Your track rod will come with all master carriers and regular carriers pre-installed.

  • Page 6: Step 6 - Attaching Returns

    STEP 7 - ATTACHING BRACKETS TO THE CEILING STEP 6 - ATTACHING RETURNS Hold the rod up and attach the brack- Slide Return onto rod and tighten CEILING CEILING et to the ceiling, aligning the holes of set screw. BRACKET BRACKET RETURN the bracket with the marks you made...

  • Page 7: Step 8 - Attaching Drapery To Rod

    ACCESSORIES STEP 8 - ATTACHING DRAPERY TO ROD Baton/Wand (optional) Insert drapery pin hooks into carriers and master carriers. CLIP Baton/Wand will be pre-attached to the master carrier(s). Split Drapery For Split drapery, start pining from MASTER DRAPERY the center and go towards the ends. CARRIERS CARRIER PINS...

  • Page 8: Care & Cleaning

    NOTES CARE & CLEANING Minimal care and cleaning is needed to maintain the beauty of your Hardware. To Vacuum: Use brush or dust head attachment. To Dust: Use soft, clean cloth. smithandnoble.com 800.248.8888...
