- Page 1 Quadrum DigiPlus / Quadrum DigiPlus Green auto auto auto x auto y IP 66 Laser 530-670 nm...
-
Page 2: General Safety Instructions
– optional SensoLite 410: Laser receiver range up to 400 m radius – optional SensoMaster 400 (Quadrum DigiPlus red only): Laser receiver range in excess of 300 m radius. With longer laser receiver unit and millimetre exact distance reading for laser level. - Page 3 The anti-drift system (ADS) prevents erroneous or inaccurate measurements. How it works: continuous monitoring of the alignment of the laser is activated 30 seconds after the ADS is switched on. If the device moves due to external factors or if the laser loses its height reference, the laser will come to a standstill and blink.
-
Page 4: Battery Charging
Quadrum DigiPlus / Quadrum DigiPlus Green Quadrum DigiPlus Green: green laser technology The distance at which a laser is visible to the naked eye depends on its colour i.e. wavelength. This is because of the human eye‘s physiology – green appears brighter to us than red. Depending on ambient light, green lasers are therefore many times more visible than red lasers;... - Page 5 Vertical operation Reference / plumb laser outlet Battery compartment / battery fastening nut Prism head / laser beam outlet Charging socket Receiver diodes for remote control (4 x) Battery compartment Control panel Rechargeable battery LC display compartment 5/8“ thread / Mains unit / charger Reference, plumb laser outlet Operation indicator...
- Page 6 Quadrum DigiPlus / Quadrum DigiPlus Green Control panel Quadrum DigiPlus auto/slope function Switching the x and y-axes Rotary speed for selection 600 / 300 / 120 / 60 / 0 rpm ON/OFF button Plus button for setting the inclination with the digital and...
- Page 7 Horizontal levelling and vertical levelling auto auto – Horizontal: Position the device on a level surface or on a tripod. – Vertical: Set the unit on its side feet. The operator panel should be at the top. With the optional wall bracket (product ref. 080.70), the device can be mounted on a tripod for vertical usage.
- Page 8 Quadrum DigiPlus / Quadrum DigiPlus Green Digital inclination function (dual grade function) The horizontal plane can be inclined digitally in the x and y-axes. The maximum inclination of a plane is up to ±10%. In the sum of both axes, the maximum value is reduced per each axis.
- Page 9 Manual slope function up to 6° – vertical auto 3 sec When the maximum slope range of 6° has been reached, the laser will stay fixed and blink and emit a sound. In this case, reduce the slope angle. Manual slope function > 6° Steeper slopes can be set using the angle plate, which is available as an optional extra (product ref.
- Page 10 Quadrum DigiPlus / Quadrum DigiPlus Green Working with the reference/plumb laser The unit has two reference lasers. In horizontal operation these lasers can be used to drop a perpendicular. In vertical operation these reference lasers are used to align the unit. This is done by adjusting the reference lasers parallel to the wall.
- Page 11 5. To check the Y and Z axis, repeat steps 3 and 4. If points A2 and A3 are more than 0,75 mm / 10 m apart on either the X or Y axis, the device is in need of adjustment. Contact your authorised dealer or else the UMAREX-LASERLINER Service Department.
-
Page 12: Adjustment Mode
Quadrum DigiPlus / Quadrum DigiPlus Green Adjustment mode 1. Take the alignment of the rotary laser into account when performing adjustment work. Always adjust all the axes. 2. Switch the device to adjustment mode: Switch off the rotary laser and switch it on again while holding the auto/slope button. Press and hold the auto/slope button until the x-axis indicator starts to flash on the display. - Page 13 Quadrum DigiPlus / Quadrum DigiPlus Green SERVICE Umarex GmbH & Co KG – Laserliner – Möhnestraße 149, 59755 Arnsberg, Germany Tel.: +49 2932 638-300, Fax: +49 2932 638-333 laserliner@umarex.de Umarex GmbH & Co KG Donnerfeld 2 59757 Arnsberg, Germany Tel.: +49 2932 638-300, Fax: -333...
