Summary of Contents for AMP Lighting InfusePro Step Light
- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® InfusePro Step Light ® ASL-601X-4-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
-
Page 2: Important Safety Instructions
INSTALLATION & MAINTENANCE GUIDE InfusePro Step Light ® ASL-601X-4-B-BZ Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. - Page 3 Package Contents A. (1) Housing C. (2) Lock Screws B. (1) Luminaire Cover with Gasket Product Dimensions 8.25” 3.25” 2.75” 7” 3” 3.5” Open Face Step Light Hooded Step Light Louvered Step Light Before Starting: 1. Desired location for each luminaire should be determined before construction of the wall is started.
- Page 4 INSTALLATION & MAINTENANCE GUIDE InfusePro Step Light ® ASL-601X-4-B-BZ Install Housing in Wall or Deck Main Low Voltage Pass the supply wires through the Supply Cable cut holes and insert the housing into the hole. Secure with screws. Hole Continue from Step 4 to complete all installations.
- Page 5 INSTALLATION & MAINTENANCE GUIDE InfusePro Step Light ® ASL-601X-4-B-BZ Install Fixture Faceplate with Gasket Housing Place the luminaire faceplate with gasket onto housing and secure with lock screws. Lock Screw Fixture Faceplate with Gasket Wire Connection Strip both leads from the luminaire Luminaire pigtail.
- Page 6 w w w. a m p l i g h t i n g . c o m –6– –6–...
- Page 7 customersupport@amplighting.com • 813.978.3900 –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-ASL-601X-$-B-BZ.pdf...
