Allegro Z6
NOTICE: The suitable enviromental temperature for this lighting fixture is between -25˚ C to 45˚ C.
Do not place this lighting fixture in an enviroment where the temperatures are under or above the
temperatures stated above. This will allow the fixture to run at its best and help prolong the fixture
life.
OMEGA BRACKET
ATTACHMENT POINTS
Screw one clamp each via a M12 screw and nut into the Omega bracket. Insert the quick-lock fasteners
of the Omega holder's into the respective holes on the bottom of the Allegro Z6. Tighten the quick-
lock fasteners fully clockwise. Pull the safety cable through the openings located on the base and
over the trussing system or a safe fixation spot. Insert the end in the carabine and tighten the safety
screw.
ADJ Products, LLC - www.adj.com - Allegro Z6 User Manual Page 8
SAFETY CABLE
3 SEPARATE CLAMP
ATTACHMENT POINTS
OMEGA BRACKET
ATTACHMENT POINTS
Installation
CLAMP
OMEGA BRACKET
