Drying tumblers 50/75 pound capacity
Hide thumbs Also See for Drying Tumblers none:
Table of Contents

Advertisement

Quick Links

See also: Troubleshooting Manual , Maintenance Manual
Drying Tumblers
NOTA: El manual en
español aparece después
del manual en inglés.
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Refer to Page 4 for Model Identification
50 Pound Capacity
75 Pound Capacity
www.comlaundry.com
Part No. 70256801R1
August 2007
