- Page 1 Clothes Dryer Electric and Gas Models DRY724C_SVG Original Instructions Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 514694ENR2 www.alliancelaundry.com April 2015...
-
Page 3: Front Matter
Installation and service must be performed by a qualified installer, service agency or the gas sup- W053 plier. This product uses FreeRTOS V7.2.0 (www.freertos.org). W052 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 4: Table Of Contents
Dryer Interior....................26 Cabinet.....................26 © Copyright 2015, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. - Page 5 Control Panel.................... 26 Exhaust System..................26 Lint Filter.....................26 Motor Overload Protector................27 For Energy Conservation................27 Troubleshooting..................28 Disposal of Unit..................29 Contact Information................30 Installer Checklist.................31 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
-
Page 6: Safety Information
• Children less than three years should be kept away unless continuously supervised. • Do not reach into the dryer if the cylinder is revolving. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... - Page 7 Common sense, caution and care must be exer- cised when installing, maintaining, or operating the dryer. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
-
Page 8: Dimensions
NOTE: Exhaust openings are 102 mm [4 inch] metal * With leveling legs turned into base. ducting. Gas Models DRY2639N_SVG 1. 3/8 in. NPT Gas Connection © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... - Page 9 For maximum drying per- formance, we recommend that more clearance be al- lowed around the dryer than the clearances that are lis- ted throughout this manual. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
-
Page 10: Installation
Any disassembly requiring the use of tools must be performed by a suitably qualified service person. W299 Order of Installation Steps 1. Position and level the dryer. 2. Connect dryer to exhaust system. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... - Page 11 Installation DRY2642N_SVG 1. Dryer Base 2. Level 3. Leveling Leg 4. Rubber Foot Figure 2 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
- Page 12 Front View (Closet Door) 2 (G) DRY2637N_SVG 1. Closet Door 2. Centered Air Openings (G) (2 Openings minimum) 3. Outer Wall of Enclosure Figure 3 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
-
Page 13: Connect Dryer Exhaust System
MUST be exhausted to the out- WARNING doors. W604 To reduce the risk of fire, DO NOT use plastic or thin foil ducting to exhaust the dryer. W354 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 14: Exhaust Direction
• Use of duct tape or pop-rivets on all seams and joints is rec- ommended, if allowed by local codes. DO NOT use sheet © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 15: Exhaust System
A direct, individual outside venting is recommended. When that ter flexible metal duct must not exceed 2.4 m [7.87 ft.]. is not possible, a collector duct as shown below may be used. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... - Page 16 2. Clean Out Cover (Must be provided). Inspect monthly. 3. Weather Hood or Sweep Elbow (No cap or screen) 4. 610 mm [24 in.] Minimum Clearance to Roof/Ground Figure 5 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
- Page 17 305 mm [12 inches] 326 mm [13 inches] 356 mm [14 inches] 381 mm [15 inches] 381 mm [15 inches] 406 mm [16 inches] Table 3 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
-
Page 18: Gas Dryers - Connect Gas Supply Pipe
NOTE: This appliance must be installed in accordance plete combustion. Refer to Table 4 . with regulations in force. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... - Page 19 For proper operation at altitudes above 1370 m [4500 feet] the L.P. gas valve spud orifice size must be reduced to ensure com- plete combustion. Refer to Table 5 . © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
-
Page 20: Reverse Door, If Desired
3. Pull bottom of door liner out, then pull down, removing door liner from door panel. DRY1918N_SVG Figure 14 7. Reinstall nine screws removed in Step 2. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 21: Wipe Out Inside Of Dryer
NOTE: Refer to Kit 756P3 for WYE (400/230 Volt, 50 Hertz, 4 wire plus Earth, 10 AMP) to Delta (230 Volt, 50 Hertz, 3 wire plus Earth, 15 AMP) conversion instruc- tions. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 22: Earth/Ground And Wiring Instructions
The dryer must be connected to a metal, permanent wiring system that is properly installed and connected to a protective earth/ground; or an equipment-earth/ground conductor must © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... - Page 23 2. Shut-Off Valve Handle 3. Air Shutter Lockscrew 4. Air Shutter 5. 3.1 mm [1/8 in.] Pipe Plug (For checking manifold pres- sure) 6. Open Position Figure 20 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
-
Page 24: Operation
Clean lint filter before each use. Figure 22 Close Loading Door 1. Close loading door. 2. Dryer will not operate with the door open. DRY2644N_SVG Figure 21 DRY2645N_SVG Figure 23 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 25: Set Fabric Selector
(cool down cycle) to ensure that items in dryer are left at a temperature that ensures that the items will not be damaged. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 26: Maintenance
DO NOT use products that contain alcohol on the control The lint filter may be washed if needed. Annually remove lint fil- panel. ter and screw to vacuum the duct under it. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 27: Motor Overload Protector
Should you plan to dry several loads, do them one after anoth- er, then you do not have to reheat the dryer unit’s interior parts each time. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 28: Troubleshooting
• Ventilate room before drying clothes. © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 29: Disposal Of Unit
MIX1N_SVG Figure 27 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 30: Contact Information
20 54 for the name and address of the nearest authorized parts Date Purchased ______________________________ distributor. Model Number ______________________________ DRY2527N_SVG 1. Serial Plate Figure 28 © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT... -
Page 31: Installer Checklist
Reverse Door, if De- Start and Run Dryer in Heat Setting to Verify Dryer is sired. Heating. CHECK CHECK DRY2052N_SVG1 Refer to the manual for more detailed information © Copyright, Alliance Laundry Systems LLC - Part No. 514694ENR2 DO NOT COPY or TRANSMIT...
