Caring for the Library

For a lifetime of reliable performance from your library, disconnect the power to the

library and perform an annual inspection of the internal components.

• Use compressed air to clean out the slots in the DCM(s).

• Use compressed air to clean out the inventory sensors on the robotic tape picker

(Figure 7-2).

• Use a soft cloth to clean the bar code scanner window on the robotic tape picker

(Figure 7-2).

• With power to the library disconnected, open the rear access panel and use

compressed air to clean out the area behind the drives.

Inventory sensors

Figure 7-2 Robotic tape picker (shown removed for clarity).

Chapter 7. Maintenance, Troubleshooting, and Repairs

LED (front)

Picker jaws (rear)

Bar code reader
