Operation
Fig. A
1.UNLOCK button
2.Power switch
3.Power-switch locking lever
4.Blade-guard cover
5.Blade-guard finger screw
6.Moving blade-guard
7.Edge of moving blade-guard
8.Adjusting wheel
9.Operating handle
10.Spindle-lock button
11.Blade-guard finger screw
12.Motor unit
13.Overload protection
14. Rating plate
15.Gripper unit
16.Gripper adjustment handle
17. Gripper safety
