Kuva A

Foreword

Operating, safety, and servicing instructions
Please read this operating, safety, and servicing instructions carefully before
using the pipe saw. Also store this instruction book somewhere accessible to
everyone using the pipe saw. In addition to these instructions, always follow
the official work, health and safety regulations. The Exact PipeCut 360 is meant
for professional use only.

Technical data

Model
Voltage
Power
Speed when unloaded
Intermittent operation
Blade diameter
Blade attachment hole
Weight
Range of use
Max. pipe wall thickness
The Exact PipeCut 360 pipe saw is manufactured in accordance with the EU standard EN 60745-1 and
also standard EN 60745-2-5 exclusive of the requirement which relates to the opening of the blade guards.
(The Exact PipeCut 360 pipe saws use is made easier by being able to open the blade guard without
tools). Also the Exact PipeCut 360 complies with the essential protection requirements of the Council
Directive 89/336/EEC as stated in the Article 4 and the tested product is in compliance with the
following Product Family standards: EN 55014-1 (2000), EN 55014-2 (1997), EN 61000-3-3 (1995)
+ Am. A1 (2001)
The sound pressure level when sawing steel, which is measured according to EN 50144:
95.5 dB(A). When sawing various types of material the sound level may vary and at times exceed
the 85 dB(A) level. Always use ear protectors to protect yourself!
Vibration level: 1.1 m/s 2 . The weighted acceleration value according to EN 50144 does not exceed 2.5
m/s 2 .

Electrical safety

The electric motor is designed to be used at the specified voltage only. It can be loaded intermittently for
2.5 min during a 10 min time span (S3 25 %). Always check that the power supply corresponds to the
voltage stated on the rating plate. The Exact 360 pipe saw is double insulated as required by standard
EN 60745-1
Do not take the pipe saw out in the rain. Never use it in wet or damp conditions.
Pipecut 360
230 / 50 Hz
1400 W
4000 r/min
S3 25%
140 (155) mm
62 mm
14,3 kg
Ø 75 mm – Ø 360 mm
steel 8 mm, plastics 12mm
3
