BUILD IN APPLIANCES
FOR USE WITH UNIVERSAL LPG ONLY
CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE
Models
S~OG72000Z SD Duplex Oven&Grill
S~OV72000Z SD Oven Only
USER AND INSTALLATION INSTRUCTIONS
PLEASE READ THOROUGHLY AND KEEP FOR FUTURE REFERENCE
FOR USE IN AUSTRALIA
THETFORD AUSTRALIA PTY LTD
41 LARA WAY CAMPBELLFIELD VIC
TEL: 03 9358 0700
FAX: 03 9357 7060
Advertisement
Related Manuals for Thetford S OG72000Z SD
Summary of Contents for Thetford S OG72000Z SD
- Page 1 S~OG72000Z SD Duplex Oven&Grill S~OV72000Z SD Oven Only USER AND INSTALLATION INSTRUCTIONS PLEASE READ THOROUGHLY AND KEEP FOR FUTURE REFERENCE FOR USE IN AUSTRALIA THETFORD AUSTRALIA PTY LTD 41 LARA WAY CAMPBELLFIELD VIC TEL: 03 9358 0700 FAX: 03 9357 7060...
- Page 2 Gas - Universal LPG Only 2.75 Kpa • This appliance is designed for use with Universal LPG and should not be converted for use with any other gas Use only the Gas Pressures specified • This appliance MUST be earthed •...
- Page 3 Fig. 1 Control Positions for Grill Operation Fig. 2 Control Positions for Oven Operation ON (FULL)
- Page 4 Fig. 3 LOW LEVEL / UNDER WORKTOP INSTALLATION 65mm minimum Air gaps must be maintained Gas escape hole, baffled 50mm minimum 18 x 40 x 230mm Wood Battens fitted each side Minimum 18 x 400mm Air gap central to appliance...
- Page 5 Above 170mm we advise verification test before installing without plate B Air gaps must be maintained C Gas escape hole, baffled - Caravan side. Refer to Thetford if side vent not possible D 280 x 340mm Heat Shield central to appliance...
-
Page 6: Important Safety Precautions
INTRODUCTION In your own interest of safety, gas appliances should be installed by competent persons. Failure to install the appliance correctly could invalidate any warranty or liability claims. This appliance shall be installed in accordance with the manufacturer’s installation instructions, local gas fitting regulations, municipal building codes, AG5601 and any other relevant statutory regulations. -
Page 7: Operation
OPERATION Operation of the Door This appliance is fitted with our unique slide under door. As you open the door fully, it slides neatly under the oven. This feature maximises the space in the kitchen area by reducing the protruding door, giving easy access to the inside of the oven. To open the door:- Pull the handle forward and down, as with any other drop down door When in fully open position push the door horizontally to slide the door in. - Page 8 OPERATION Using the Grill - cont. On first use of the grill, it should be heated for about 20 minutes to eliminate any residual factory lubricants that might impart unpleasant smells to the food being cooked. A non- toxic smoke may occur when using for the first time so open any windows and turn on mechanical ventilators to help remove the smoke.
- Page 9 OPERATION 7. To turn off: turn the control knob clockwise until the circle on the control knob is aligned with the dot on the control panel. To remove a shelf, pull forward until it stops, raise at front and remove. On first use of the oven, it should be heated for about 30 minutes at gas mark 5 to eliminate any residual factory lubricants that might impart unpleasant smells to the meals being cooked.
- Page 10 Who to Contact For service and replacement parts, please contact your authorised local Service Agent giving full details of the model, serial number and date of purchase. Manufactured by: THETFORD Limited. Unit 6 Brookfields Way, Manvers Rotherham S63 5DL. England •...
-
Page 11: Installation
INSTALLATION Regulations and Standards In your own interest of safety, gas appliances should be installed by competent persons. Failure to install the appliance correctly could invalidate any warranty or liability claims. This appliance shall be installed in accordance with the manufacturer’s installation instructions, local gas fitting regulations, municipal building codes, AG5601 and any other relevant statutory regulations. - Page 12 INSTALLATION Fixing Fixing screw positions are located on each side of oven opening and are accessed by opening the door. Screw into place using a flange head No 6 woodscrew WARNING When installing DO NOT lift appliance using the door handles. Connection A ¼...
-
Page 13: Maintenance And Servicing
MAINTENANCE & SERVICING IMPORTANT • Shut off gas supply at isolating valve, switch off electric supply and ensure all parts are cool before cleaning or servicing • All servicing must be carried out by an approved competent person. • After each service the appliance must be checked for gas soundness •... - Page 14 MAINTENANCE & SERVICING 6. Grill burner injector (No62) Disconnect from gas supply (1). Remove appliance from housing (2). Release injector holder from bracket, disengage the grill pipe from the control and remove the injector. 7. Oven burner injector (No62) Open the oven door and unscrew the burner retaining screw, slide the burner to the left and lift out.
