BUILD IN APPLIANCES
FOR USE WITH LIQUIFIED PETROLEUM GAS
CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE
Models
S ~ OG72000 SD Duplex Oven&Grill
S ~ OV72000 SD Oven Only
USER AND INSTALLATION INSTRUCTIONS
PLEASE READ THOROUGHLY AND KEEP FOR FUTURE REFERENCE
FOR USE IN
GB, FR, DE, NL, ES, IT, SI, SE, NO, DK, PT, FI, AT, CH, IE, BE, LU
THETFORD LIMITED
Unit 6 Brookfields Way, Manvers
Rotherham S63 5DL. ENGLAND.
+ 44 (0) 844 997 1960
+ 44 (0) 844 997 1961
Advertisement
Table of Contents
Related Manuals for Thetford Duplex
Summary of Contents for Thetford Duplex
- Page 1 FOR USE WITH LIQUIFIED PETROLEUM GAS CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE Models S ~ OG72000 SD Duplex Oven&Grill S ~ OV72000 SD Oven Only USER AND INSTALLATION INSTRUCTIONS PLEASE READ THOROUGHLY AND KEEP FOR FUTURE REFERENCE...
- Page 2 CAUTION • Appliance and accessible parts become hot when the grill is in use, young children should be kept away. Avoid touching the heating elements or pan supports when in use. • The use of a gas cooking appliance results in the production of heat, moisture and products of combustion in the room in which it is installed.
- Page 3 CAUTION • Do not use harsh abrasive cleaners or sharp metal scrapers to clean the glass door since they can scratch the surface, which may result in shattering of the glass. • Do not use steam cleaners or pressure washers to clean the appliance.
-
Page 4: Appliance Specifications
APPLIANCE SPECIFICATIONS Appliance Appliance DUPLEX OVEN Model Range Model Range S-OG72000 S-OV72000 Grill & Oven Oven Only 527 530 32.4 ltrs 32.4 ltrs Components Components g/hr g/hr 0.62 0.52 0.59 g/hr g/hr 78 mA 142 mA 0.9 W 1.7 W 14.5 kg... - Page 5 Fig. 1 – Low Level/Under Worktop Installation To ensure correct operation the installation must allow for free exchange of air between the enclosure and the living environment. Design constraints may dictate additional venting at front of installation. 65mm Minimum Air Gaps must be maintained Gas dispersal hole, baffled 50mm Minimum E 18 x 40 x 230mm Wood Battens fitted each side of aperture...
- Page 6 Above 170mm we advise undertaking verification test before installing without shield B Air Gaps must be maintained C Gas Dispersal hole, baffled – Caravan side. Refer to Thetford if side vent not possible D 280 x 340mm Heat Shield central to appliance E When installed above fridge the shelf MUST be sealed to prevent unburnt gas from entering the fridge compartment.
- Page 7 Fig. 3 – Grill Operation, Control Positions Fig. 4 – Oven Operation, Control Positions FULL RATE...
-
Page 8: Operation
INTRODUCTION This appliance is designed for cooking foods, any other use is incorrect and may be dangerous. Failure to install the appliance correctly or improper use, will invalidate any warranty or liability claims. This appliance must be installed in accordance with the local, national and European regulations in force. - Page 9 OPERATION Using the Grill 1. Ensure gas cylinder/supply is connected and turned on. 2. Open door, push in the control knob and turn clockwise to the large flame symbol – ( ) see Fig. 3. 3. Continue depressing the knob whilst holding a lighted match to the burner. For models fitted with spark ignition the procedure is similar except that burner is ignited by depressing the ignition button located on the fascia.
- Page 10 OPERATION Operation of the Door This appliance is fitted with our unique slide under door. When the door is opened fully, it slides neatly under the oven. This feature maximises the space in the kitchen area by reducing the protruding door, giving easy access to the inside of the oven. To open the door: Pull the handle forward and down, as with any other drop down door.
- Page 11 OPERATION • The grill pan supplied is multi functional, for use in grill or oven. • The handle design allows removal or insertion whilst pan is in use. • Always remove the handle when the pan is in use. • The grill MUST only be used with the door open. Using the Oven 1.
- Page 12 OPERATION Temperature Control The temperature in the oven is controlled by a thermostatic gas tap and is variable over the range 130°C to 240°C. The table below provides a guide to the approximate temperatures at each of the shelf positions with respect to the gas mark setting. Good use can be made of the temperature variation between the shelf positions in several dishes requiring different temperatures may be cooked at the same time.
-
Page 13: Maintenance
MAINTENANCE We recommend an annual service by an authorised service agent to maintain efficient appliance performance. In between annual service the appliance needs little maintenance other than cleaning. All parts should be cleaned using warm soapy water. Do not use abrasive cleaners, steel wool or cleansing powders. -
Page 14: Installation
INSTALLATION This appliance must be positioned free from draughts, which may affect the combustion, and in a manner that will prevent the accumulation of unburnt gas. When in use ensure that air vents are not inadvertently blocked or shut off. Ensure all combustible materials such as curtains and shelves are well clear of the appliance. - Page 15 European Standard (EN 30-1). If it is not possible to install the appliance as detailed within these instructions please refer to Thetford Ltd for guidance.
- Page 16 SERVICING All servicing must be carried out by an approved competent person. Before any service work is started the appliance should have been left to cool and be disconnected from both the gas and electrical supplies. After each service the appliance must be checked for gas soundness.
- Page 17 6. Grill burner injector (No62) Disconnect from gas supply (1). Remove appliance from housing (2). Release injector holder from bracket, disengage the grill pipe from the control and remove the injector. 7. Oven burner injector (No59) Open the oven door and unscrew the burner retaining screw, slide the burner to the left and lift out.
