- Page 1 BUILD IN APPLIANCES FOR USE WITH PROPANE GAS MODELS S~OH70000Z - TRIPLEX S~OH71000Z – TRIPLEX DUAL FUEL USER AND INSTALLATION INSTRUCTIONS PLEASE READ THOROUGHLY AND KEEP FOR FUTURE FOR USE IN AUSTRALIA THETFORD AUSTRALIA PTY LTD 41 LARA WAY CAMPBELLFIELD VIC...
- Page 4 SPECIFICATION TRIPLEX TRIPLEX TRIPLEX TRIPLEX TRIPLEX Model Range S~OH70000Z S~OH70000Z S~OH70000Z S~OH70000Z S~OH71000Z External Dimensions, mm 468 x 456 x 500mm 468 x 456 x 500mm 468 x 456 x 500mm 468 x 456 x 500mm 468 x 456 x 500mm...
- Page 5 INTRODUCTION In your own interest of safety, gas appliances should be installed by competent persons. Failure to install the appliance correctly could invalidate any warranty or liability claims. This appliance shall be installed in accordance with the manufacturers installation instructions, local gas fitting regulations, municipal building codes, AG5601 and any other relevant statutory regulations.
- Page 6 OPERATION WARNING • The appliance is not intended for use by young children or infirm persons, without supervision • Young children should be supervised to ensure they do not play with the appliance. • Glass lids may shatter when heated. Turn off all burners before shutting the lid •...
-
Page 7: Operation
OPERATION WARNING • Glass lids may shatter when heated. Turn off the hotplate and allow it to cool before closing the glass lid. • Remove all spillage from the surface of the glass lid before opening. Using the Electric Hotplate Ensure the electricity is switched on. - Page 8 OPERATION IMPORTANT • The grill MUST only be used with the door open. • When grilling the oven shelf should be located on the middle runner. • The heat deflector below the fascia should be pulled out prior to lighting the grill.
- Page 9 OPERATION WARNING When cooking always ensure young children are kept away. Using the Oven Ensure gas cylinder/supply is connected and turned on. In the event of a gas smell turn off at gas cylinder/mains and contact supplier. To light: Open door, push in the control knob and turn to full rate (Gas Mark 9, 240°C). Hold a lighted match or taper to the burner and push the control knob in and hold.
- Page 10 OPERATION Do's and Don'ts Read the user instructions carefully before first use of the appliance. Allow the oven to heat before using for the first time, in order to expel any smells before the introduction of food. Clean the appliance regularly. Remove spills as soon as they occur.
-
Page 11: Installation
INSTALLATION Regulations and Standards In your own interest of safety, gas appliances should be installed by competent persons. Failure to install the appliance correctly could invalidate any warranty or liability claims. This appliance shall be installed in accordance with the manufacturers installation instructions, local gas fitting regulations, municipal building codes, AG5601 and any other relevant statutory regulations. - Page 12 The appliance can be front or side fixed, holes are provided for either installation method. Fixing screw positions are located as follows. Appliance Front Fixed Appliance Side Fixed Appliance S~OH70000Z 2 front fix holes each side of 2 side fix holes each side of & Oven opening...
- Page 13 INSTALLATION Connection - Electrical The appliance is supplied with a power cord and plug which must be connected to a double pole switched mains supply, with 3mm minimum contact separation at all poles. Any excess power cord MUST be routed away from the appliance and not come into contact with the appliance or hang loose into a lower compartment.
-
Page 14: Maintenance And Servicing
Who To Contact For service, please contact your authorised local Service Agent giving full details of the model, serial number and date of purchase. Manufactured by: THETFORD Limited. Unit 19 Oakham Drive, Parkwood Industrial Estate, Rutland Road, Sheffield. S3 9QX. England. - Page 15 MAINTENANCE AND SERVICING 4. Control replacement Hob controls Disconnect from gas supply (1). Remove hob surface (2). Unscrew the corresponding pipe and thermocouple and remove from the control. Open the oven door and unscrew the 2 screws holding the thermostat probe in position and push the probe back out through the hole in the rear of oven.
