PF SERIES
RKC INSTRUMENT INC.
Ramp/Soak Controller
This manual describes mounting, wiring and basic
operation only. Refer to the PF900/PF901 Instruction
Manual on the CD-ROM for Host communication,
control (Fixed set point control, Manual control
etc.), operation for function and Troubleshooting.
PF900
PF901
User's Manual
IMR02L04-E3
