swissflex uni 14_75RF bridge basic Operating Instructions Manual page 20

uni 14_/22_/20_75RF basic «Classic»
Radio remote control RF-Classic
1 Control system back section «up»
2 Control system back section «down»
3 Control system thigh section «up»
4 Control system thigh section «down»
5 All motors «up»
6 All motors «down»
7 Pocket lamp
8 Battery compartment
(back of radio remote control)
9 3 x AAA-Battery (included in the delivery)
Motor control
11 Connection for mains supply unit
12 Teach-in button / emergency lowering
button (on the external radio receiver)
13 Connection for external radio receiver
14 Switching power supply
15 Battery compartment for emergency
lowering (2 x 9 V)
20
Operating instructions
1
3
5
7
8
13
14
uni 21_75RF
A575R
2
4
6
11
12
15
8
9
EN
