Initial setup «Touch»
Place the batteries into the radio remote control
Remove the cover from the battery compartment (9)
on the back of the radio remote control. Place 3 AAA-
batteries (10) into the compartment, paying attention
to the +/- markings. Close the compartment cover
again. The maximum range of the radio remote con-
trol is 15 metres.
Teaching-in the radio remote control (already
taught-in in the factory)
1. Remove the radio remote control's battery cover on
the back of the device.
2. Insert / check the batteries (3 x AAA).
3. Activate the teach-in button (12) on the radio re-
ceiver (press 2 x). It flashes after successful acti-
vation.
4. A small red button is located above the batteries in
the battery compartment of the device.
5. Press the button; a blue LED will start flashing.
6. Hold the button down until the blue LED is per-
manently illuminated; this means that pairing has
been completed.
Pocket lamp
The pocket lamp is illuminated when the „Pocket
lamp" button (1) is held down. The light turns off
when the button is released. This button is illuminat-
ed (blue) while the pocket lamp is in use.
Adjustment options «Touch»
You can individually adjust the back section or the
thigh section by using the buttons (5-8).
All motors can be simultaneously put in position «up»
or «down» with the buttons (2) and (3).
To reset to the horizontal position
Press the "all motors down" button (3) to simultane-
ously move all sections to the horizontal position.
Care and Maintenance «Touch»
Your uni 14_/22_/20_75RF basic is a high-quality
product that has been designed to serve you reliably
for many years to come. For occasional cleaning and
the removal of dust, we recommend the use of a dry
cloth.
Changing the batteries in the radio remote control
Remove the cover from the battery compartment (9)
on the back of the radio remote control. Place three
AAA batteries into the compartment, paying attention
to the +/- markings. Close the compartment cover
again.
18
Operating instructions
Changing the batteries at the switching power sup-
ply of the uni 14_/22_/20_75RF basic (batteries for
emergency lowering)
Remove the cover of the battery compartment (15) on
the underside of the switching power supply. Careful-
ly remove the batteries from the battery clips. Place
two 9V block batteries in the compartment, paying
attention to the +/- markings. The batteries provide
power in the case of a power failure.
Troubleshooting «Touch»
In case of malfunctions with your uni 14_/22_/20_75RF
basic, consult the following troubleshooting tips. If
the problem cannot be resolved, disconnect the uni
14_/22_/20_75RF basic from the mains outlet and
contact your Swissflex stockist.
Loss of power in the sitting position; emergency
lowering button
The switching power supply contains two bloc batter-
ies (29) to revert the bed to the horizontal (sleeping)
position in the event of a power failure while sitting
up in the bed:
Hold the emergency lowering button (12) down on the
radio receiver until all sleeping surfaces are in the
horizontal position.
Use of the emergency lowering button consumes a
great deal of battery power, which means you will
need to replace the batteries.
The uni 14_/22_/20_75RF basic does not work de-
spite being switched on and all components being
connected properly
Disconnect the mains supply unit from the mains out-
let. Wait a minute and then reconnect it. If necessary,
connect a bedside lamp to check that mains voltage
(240 V) is present. If there is no current, check the
fuse.
Press the "all motors down" button (3) to reset all
adjustments. The control of the uni 14_/22_/20_75RF
basic contains microprocessors, so irregular power
supply can lead to malfunctions.
The radio remote control does not work (The back-
ground light does not work)
Insert new batteries. Where applicable, remove any
obstacles between the radio remote control and the
radio receiver.
