Applying Power

‚ Plug the power cord into an AC wall outlet and into the back of the ELI 150 Rx. (Reference Figure
1-3.) Device powers on automatically and cannot be turned off when AC is connected (device is in
Standby mode).
ƒ If using battery power, press the power ON/OFF button
keyboard. (Reference Figure 1-5.)
Indicators on the keyboard will illuminate as follows:
• The AC power LED indicator illuminates when device is connected to mains (AC power).
• The battery LED indicator illuminates when charging and flashes when battery is low
(below 11.0V); it will turn off when the battery is fully charged.
The ELI 150 Rx should be connected to AC power for recharging when not in use.
TIP: Battery voltage is displayed at the bottom of Time/Date screen.
NOTE: For typical usage, battery charging time should be approximately 8 hours or less.
NOTE: Two AC line fuses and one battery fuse are installed on your ELI 150 Rx.
CAUTION: When the battery charge is depleted to its lowest level (10.5V), the device will
automatically power down. To recharge a battery from its lowest level, 30 hours of recharging
without operation may be necessary. Routinely discharging a battery to this level will severely
shorten the life of the battery.

Setting Time, Date, and LCD Contrast

‚ From real-time ECG view, select F6 (More).
ƒ Using the keyboard, select 3 (Set Time/Date) from the application menu.
„ The preprogrammed date and time is displayed. To make changes, type in the desired date and time values
(using a 24-hour clock) in the same format as displayed. Use F1 (L) and F2 (M) to move back and forth
through each row.
TIP: Use the BACKSPACE
… LCD contrast can be adjusted by selecting F3 (LcdL) or F4 (LcdM).
† Select F5 (Save) to save changes before exiting.
› Select F6 (Exit) to return to real-time ECG view. If you did not save before selecting Exit, any changes
made to the time, date, or LCD contrast will be lost.
key to erase entry errors.
located on the lower right side of the
