To exit the "Setup" mode, double click the "Middle" button.
FM Radio with intercom
When you are in "FM Radio" mode it is not possible to manually open the intercom, you
can only open it using VOX feature (just talk) to the unit paired on the "Middle" button. To
manually activate the intercom you must switch to "Intercom" mode.
FM Radio in background
It is not possible to have the FM radio along with other audio sources. Any
active audio such as Intercom or coming from the VOL+ or VOL- connection,
will pause the FM radio.

Wired audio input

Your Midland BTNEXT PRO can be connected to a wired audio source, like an iPod (or
any other MP3 Player).
Listening to music
To listen to music from the wired input, connect the audio source using the optional AUX
cable. The volume buttons (Vol + and Vol -) can be used to adjust the volume of the wired
audio source (but not independently from the Intercom Volume). The AGC system will
automatically increase the volume on higher speed.
Attention: never set the volume of the MP3 Player to the maximum possible. Normally the
best level is about the 70% of the maximum.
Hint: We recommend that you perform a few tests adjusting the volume of your iPod/MP3
player so at the normal speed the Headset volume is suited to your needs. The AGC system
will automatically increase the volume on higher speed, so you don't need the VOL+ or VOL-
buttons to adjust it.
Enabling/disabling the wired input
If needed the wired input can be enabled or disabled:
Enabling/Disabling: Make a Long press (3 sec.) on the "Forward" and "Middle" buttons
(you will hear one audio beep tone for enabling confirmation and two audio beep tones
for disabling). This setting is rembered also after turning On/Off the unit.
34
Wired audio in background
The audio from the wired connection can be in background to your Intercom or Phone
communication. By default this option is ON. Please refer to the paragraph "Wired con-
nection always in background" below to disable it.
Note that is not possible to have the wired audio source in background to the FM radio.

Emergency Stop light

On the back of your BTX1 PRO mounting kit you have an ultra bright
LED emergency stop light. Every time you make a full brake, the
stop light will turn ON to give an extra alert to the drivers behind
you. In case you need to turn it OFF temporarily (for example
when you ride with a passenger), just press long "Backward" and
"Forward" button together while in "Phone" or "Intercom" mode
(a voice announcement will confirm the status). The unit will re-
member the last setting used, that mean you need to turn ON
manually the stop light pressing again "Backward" and "Forward"
button togheter.
Attention: By default the stop light is OFF

Setup and special configurations

Resetting all paired devices
Sometimes you may find it necessary to delete all the pairing references stored in the
Midland BTNEXT PRO unit (reset operation).
To perform this operation you must first enter the setup mode:
› Turn off the unit
› Press and hold down the "Middle" button about 7 sec., until the Red light is on per-
manently.
› Then simultaneously press and hold down the "Volume +" and "Volume –" buttons for
3 seconds. The Blue Light will be lit on for 1 sec and then back to steady RED.
› Double click on the "Middle" button to exit the "Setup" mode and use the Midland
BTNEXT PRO.
This procedure deletes all the paired Bluetooth devices stored in the memory and it is
Stop Light
