F. Suggested Spare Parts
The suggested spare parts list below contains parts that may require
replacement during service visits or periodic maintenance. These parts can
maintain the reliability, quality, and performance of the BLM550+ Booklet Maker.
This list is provided as a courtesy. A complete parts list is available in the Spare
Parts Catalogue of the BLM550+ Booklet Maker.
Table 15 – BLM550+ Booklet Maker Suggested Car Stock
BELT, (PSQ) TRIMMINGS REM 2
RUBBER, ANTI-STATIC CONVE 2
CLUTCH, (PSQ)CB6 CCW 24v 1
PCB ASSEMBLY, PSQ AXIS MO 1
BELT, OUTFEED MAT 02H-25- 2
BELT, (PSQ) 2MRx6x288 2
BELT, T5-16-1160LG 2
BELT, MAT 02H-25-269mmLG 4
IONISER BAR, END ENTRY 91 1
KLUEBER ISOFLEX NBU15 GRE 1
CABLE ASSY, PSQ STITCH SWI 1
CABLE ASSEMBLY,PSQ TRIM H 1
1060125837 7257PS, G8 CLINCHER POINT 2
BEARING,ROLLER FLANGE 22M 2
BEARING, FLANGED ROLLER 8 2
P.ASSY, (PSQ) INFEED QUADR 1
SCREW, SKT HD CAP, M5X25 HI 2
SCREW, SKT HD CAP, M4X30MM 2
1060123019 SPRING,EXT Pkg of 8
SHAFT, (PSQ) CROWNED ROLL 1
PL MLDING, (PSQ) SIDE LAY 1
NYLON, SHLDER WASHER 18.3 2
PIN, (VDPS) dia 3mm x 24 2
CABLE ASSY, (PSQ) 10W HIG 1
P.ASSY, (PSQ) PICKUP FING 2
BELT, MAT 02H_25-1500 2
Belt, t5-340-10 2
BELT, MAT 02H-25-1500 2
BELT, MAT-02H X 25 X 447 2
BELT, MAT-02H X 25 WIDE X 2
FUSE T16A 2
1
Item Numbers and Part Numbers are subject to change without notice.
BLM550+ Booklet Maker Service Support Guide
Revision 1
BLM550+ Booklet Maker Service Support Guide
Item
1
Item Number
1060059271
1060059307
1060059322
1060059327
1060059348
1060059349
1060059356
1060059357
1060059360
1060060886
1060061836
1060061838
1060069177
1060072946
1060074061
1060080171
1060080814
1060080831
1060080951
1060081435
1060081568
1060081632
1060081652
1060081778
1060082011
1060082208
1060082209
1060082212
1060082216
1060082218
1060084207
March 2015
Page 14
