INDEX PART
NO. NO. PART NAME
73 203321 CABLE ASSY, OUTERMAST
SWITCH
74 023319 CABLE ASSY, MAST, 5 COND
75 005652 CONNECTOR, HOUSING, 8 PIN
76 023323 HARNESS, STAGING VALVES
77 023320 HARNESS, DM & CYL SWITCHES
78 057510 GROMMET, RUBBER
79 056136 CLAMP, CABLE, 7/16" DIA
80 077030 WASHER, FLAT, #10
81 077207 WASHER, LOCK, SPLIT, #10
82 071377 SCREW, TRS HD, #10-32 X 3/4
83 — VALVE ASSY
84 606643-01 TUBE ASSY (158 IN LIFT)
84 606643-02 TUBE ASSY (194 IN LIFT)
84 606643-03 TUBE ASSY (212 IN LIFT)
902997
NO.
REQD.
1
1
1
1
1
1
3
2
2
2
(FIGURE 12-20) 1
1
1
1

INDEX PART
NO. NO. PART NAME
85 506621-01 HOSE ASSY (158 IN LIFT)
85 506621-08 HOSE ASSY (194 IN LIFT)
85 506621-08 HOSE ASSY (212 IN LIFT)
86 504314-02 HOSE, TILT FORWARD (42" BASE)
86 504314-04 HOSE, TILT FORWARD (48" BASE)
86 504314-06 HOSE, TILT FORWARD (54" BASE)
87 026128 NIPPLE, HOSE, 3/8
88 026707 ELBOW
89 025111 STRAIGHT FITTING, 3/8
90 025120 ELBOW
91 026911 FITTING
92 025118 ELBOW
93 025525 MALE ELBOW
94 025111 STRAIGHT FITTING, 3/8
95 060317 CLEVIS PIN
96 060425 COTTER PIN
97 506741 LEVER, VALVE
98 506740 LEVER, VALVE
NO.
REQD.
(FIGURE 12-20)
(FIGURE 12-20)
(FIGURE 12-20)
(FIGURE 12-20)
12-51
1
1
1
1
1
1
1
1
1
2
2
1
1
1
2
2
1
