Summary of Contents for Barco AMM215WTTP
- Page 1 USER’s GUIDE AMM215WTTP LCD Color Display...
-
Page 3: Table Of Contents
Warnings and Cautions 1 Warnings ........................2 Cautions ........................3 Symbol Definitions ....................... 4 Introduction 10 About AMM215WTTP Series ..................10 Touch Screen for AMM215WTTP ................10 Package Overview .....................11 Installation 13 Product Overview .......................13 Front View ......................13 Bottom View (Without Stand) .................13 VESA Mount for Your Monitor ..................14... - Page 4 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
- Page 5 Medical application. Barco, Inc. reserves the right to make improvements in the product(s) described herein. Please use rear cover page with Barco contact points or phone your local Barco, Inc. sales representative or agent for information on changes and new products.
-
Page 6: Warnings
Warnings Warning TO AVOID POTENTIAL SERIOUS INJURY TO THE USER AND THE PATIENT AND/OR DAMAGE TO THIS DEVICE, THE USER MUST: 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. -
Page 7: Cautions
1. The AC Adapter must be plugged into a grounded power outlet. 2. Use only the proprietary AMM215WTTP power supply for the AMM215WTTP monitor. 3. Turn power off when unit is not in use. Disconnect the power plug from AC outlet if the 4. -
Page 8: Symbol Definitions
General warning sign For indoor use only of risk of danger Tested to comply with FCC Class B standards Dangerous: High Voltage DC power control switch Direct Current Serial Number Medical Equipment With respect to electric shock, This way up only in accordance with Fragile, handle with care E472062... - Page 9 EU Declaration of Conformity for Medical Applications be found in the addendum which accompanied this manual. For a copy of the Declaration of Conformity document, please contact Barco, Inc. and request for AMM215WTTP DOC. Cleaning Your Monitor cleaning this LCD monitor. However, it is suggested to use a soft cloth moistened with mild detergent to clean the display housing.
- Page 10 Indications for use: This monitor is intended to be used in Health Care Facilities and Operating Rooms as a Touch User Interface tool in displaying and viewing digital images . It is not intended for diagnosis. This product contains electrical waste or electronic equipment. It must not be disposed of as unsorted municipal waste and must be collected separately.
- Page 11 AMM215WTTP in the Consult the tables below for guidance in placing the AMM215WTTP. Manufacturer's Declaration - Electromagnetic Emission The user of AMM215WTTP should assure that it is used in such an environment. Emission test Compliance...
- Page 12 Note: Ut is the A.C. mains voltage prior to application of the test level. Manufacturer's Declaration - Electromagnetic Immunit or the user of AMM215WTTP should ensure that it is used in such an environment. Immunity Test IEC 60601 Test Level...
- Page 13 Recommended Separation Distances Between Portable and Mobile RF Communications Equipement and the AMM215WTTP System The AMM215WTTP system is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the AMM215WTTP system can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications output power of the communications equipment.
-
Page 14: Introduction
Introduction About AMM215WTTP Series The AMM215WTTP Touch screen LCD Monitor displays information from imaging systems and devices. Features include: • Direct Analog signal input • Direct Digital signal input • • • 21.5" viewable display area - 16:9 aspect ratio •... -
Page 15: Package Overview
Package Overview VGA Signal Cable LCD Display Power Cord USB Cable ( A to B) DVI-D Cable DC Power Supply Cable Cover Screw Quick Start Guide Operation Manual and Touch Driver CD Manual *Accessories might change depending on region. - Page 16 Unpacking the Monitor Before you unpack your monitor, prepare a suitable workspace. You need a stable and level surface near a grounded wall outlet in an area which is relatively free of glare from sunlight or other sources of bright light. The monitor is cooled by natural convection (it has no fan). For optimum performance, do not block the cooling vents.
-
Page 17: Installation
Installation Product Overview • Front View • Bottom View (Without Stand) DC IN RJ-Type... -
Page 18: Vesa Mount For Your Monitor
Flat Panel Mounting Physical Mounting Interface by VESA This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface table arms. The VESA mounting interface is located on the back of your monitor. 100.0 mm Slots(X6) VESA Mounting Interface Warning Please select the proper screws! The distance between the back cover surface and the bottom of the screw hole is... -
Page 19: Start Your Installation
Start Your Installation Please follow these instructions so that you can hook up the cables to associated connectors. 2. Move the stand into position as seen in the step 1 diagram. 3. Remove the cable cover as seen in the step 2 diagram. 4. -
Page 20: Connecting The Display
Connecting the Display 1. Be sure all equipment is turned off. 2. Connect the DC plug to the power connector on the monitor and the other end into an electrical outlet. D-SUB or DVI connector of your host computer and tighten the screws. 4. -
Page 21: Figure
Figure... -
Page 22: User Controls
User Controls Back Panel Controls Icon Key Name Menu Down Select Power Menu off status Menu on status Menu appear Brightness Contrast Select sub-item function... -
Page 23: How To Use The Osd Menus
How to Use the OSD Menus Icon Key Name Menu Down Select Power 1. Press the “Menu” button to pop up the “on-screen menu” and press “Up” or “Down” button 2. Choose the adjustment items by pressing the “Select” button. 3. -
Page 24: On-Screen Display Menus
On-Screen Display Menus Main OSD Menu: ITEM CONTENT Contrast The monitor luminance level control. Brightness The monitor backlight level control. Auto Adjust Fine-tune the image to full screen automatically. Left/Right Moving screen image horizontal position to left or right. Up/Down Moving screen image vertical position to up or down. -
Page 25: Appendix
Appendix Troubleshooting persists, please contact your local dealer or our service center. Problem: No image appears on screen. as described in the “Installation” section. Problem: Partial Image or incorrectly displayed image. display. graphic card to make it compatible with the LCD display. Problem: Image is scrolling graphics card to make it compatible with the LCD display. -
Page 26: Warning Signal
Warning Signal If you see warning messages on your LCD screen, this means that the LCD display cannot receive a clean signal from the computer graphics card. Below are the three kinds of Warning Signal. Please check the cable connections or contact your local dealer or our service center for more information. -
Page 27: Product Dimensions
Product Dimensions 517.4mm 46.0mm 249.6mm... -
Page 28: Compatibility Modes
Compatibility Modes Mode Resolution H-Frequency(khz) V-Frequency(hz) IBM VGA 720X400 31.47 IBM VGA 640X480 31.47 Apple MacII 640X480 35.00 VESA VGA 640X480 37.86 VESA VGA 640X480 37.50 VESA SVGA 800X600 35.16 VESA SVGA 800X600 37.88 VESA SVGA 800X600 48.08 VESA SVGA 800X600 46.88 Apple Mac... -
Page 29: Touch Screen Driver Installation
Touch Screen Driver Installation The AMM215WTTP is available with USB connections. The touch driver is located on the enclosed CD-ROM for these operating systems: VISTA, XP, 2000, CE, XP Embedded, Please Note: 1. The AMM215WTTP is Microsoft® Windows® HID (Human Interface Device) compatible if you use the USB touch screen interface. - Page 30 ® If you are using a PC running Windows CE, follow the instructions below: 1. Power on the computer. 2. Make sure that the USB cable is connected to the computer. ® If you are using a PC running Linux or Apple Mac OS, follow the instructions below: 1.
-
Page 31: Description Of Warranty
Description of Warranty workmanship. Barco warrants that the product purchased is manufactured from new Subject to the conditions and limitations set forth below, Barco will, at its option, either repair any component of its products that prove defective by reason of improper or with an equivalent product. - Page 32 (18) months, (LCD panels and touch screens for a period of twelve (12) months) after the date of shipment. performed by Barco or its ASC. No goods are to be returned to Barco or its ASC without prior authorization. Buyer will be responsible for packaging (preferably original container) and shipping the defective goods to Barco or its ASC, shipping charges prepaid.
-
Page 33: Environmental Information
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. your municipal waste disposal service. For details, please visit the Barco website at: Turkey RoHS compliance... - Page 36 Barco NV President Kennedypark 35 8500 Kortrijk Belgium Barco, Inc. 1421 McCarthy Blvd. Milpitas, CA 95035 U.S.A. www.barco.com R5911667-01 2019/02...
