AUTO - SCANNING WITH DIGITAL CONTROL
LCD COLOR MEDICAL MONITOR
AMM215WTD
Operation Manual
For future reference, record the serial number of your display
monitor in the space below :
Serial Number
The serial number is located on the back of the monitor

Advertisement

Table of Contents
loading

Summary of Contents for Barco AMM215WTD

  • Page 1 AUTO - SCANNING WITH DIGITAL CONTROL LCD COLOR MEDICAL MONITOR AMM215WTD Operation Manual For future reference, record the serial number of your display monitor in the space below : Serial Number The serial number is located on the back of the monitor...
  • Page 3 Barco, Inc. 2019 All other trademarks are the property of their reference owners. This document is subject to change without notice. Barco provides this information as reference only. Reference to other vendor’s products does not imply any recommendation or endorsement. Revision Control Document number Rev.
  • Page 4: Table Of Contents

    User Function / Messages................. OSD Section ....................Troubleshooting ..................Specifications of (AMM215WTD) .............. Classification ..................... Electromagnetic Compatibility ..............Dimension Drawing (mm) of AC Adapter ........... Dimension Drawing (mm) of AMM215WTD..........Connectors ....................Description of Warranty ................Accessory Item List ..................
  • Page 5: Product Description And Intended Use

    • AMM215WTD LCD Monitor (the equipment that displays information, graphic data, image and video on the LED screen) and two video cables (1) HD15 VGA cable (1) DVI-I cable AC Power cord* •...
  • Page 6: Warnings And Cautions

    Federal law (United States of America) restricts this device to use by, or on order of a physician. The Barco, Inc. AMM215WTD monitor has been tested under UL (ANSI/AAMI ES 60601-1) standard and UL listed for Medical application. Barco, Inc. reserves the right to make improvements in the product(s) described herein.
  • Page 7 AMM215WTD 5 Warnings 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked by qualified personnel before operating it any further.
  • Page 8 Cautions 1. The AC Adapter must be plugged into a Grounded power outlet. 2. Use only the proprietary AMM215WTD power supply for the AMM215WTD monitor. Make a proper connection by ensuring that the shrink tubing completely secures the connection between the DC power cord and the extension cord.
  • Page 9: Symbol Explanations

    AMM215WTD 7 Symbol Definitions Dangerous: High Voltage Indicates Protective Earth Ground. For Indoor Use Only. Direct Current Tested to Comply with FCC Serial Number Class B Standards. This Way Up Stand-By Fragile, Handle with Care Tested to Comply with Japan...
  • Page 10: Eu Declaration Of Conformity For Medical Applications

    For a copy of the Declaration of Conformity document, please contact Barco, Inc.. and request the AMM215WTD DOC. Prepare to Unpack Monitor Before you unpack your monitor, prepare a suitable workspace. You...
  • Page 11: Safety Precaution

    AMM215WTD 9 Safety Precaution · Avoid placing the monitor, or any other heavy object, on the power cord to prevent fire or electrical shock from damage to the power cord. · Do not expose the monitor to rain, excessive moisture, or dust to avoid fire or shock hazard.
  • Page 12: Power Management Function

    LED blinks for 1 second On and 1 second Off. The screen is displayed after the vertical and horizontal sync signals are restored. Power Management System The AMM215WTD Medical Monitor power management proposal provides four phases of power saving modes by detecting the horizontal sync signal as shown in the table below.
  • Page 13: Preset Modes

    AMM215WTD 11 PRESET MODES DVI and VGA Input Signal Formats Horizontal Vertical Pixel clock Resolution frequency frequency ( MHz ) ( KHz ) ( Hz ) 640 x 350 @70Hz 31.469 70.087 25.175 640 x 480 @60Hz 31.469 59.940 25.175 640 x 480 @75Hz 37.500...
  • Page 14: Video Signals

    User’s Guide Video Signals Component Format DVI 1/2 C-Video RGB+ RGB+ Y/Pb/Pr NTSC 480/59.94i 480/59.94p 576/50i 576/50p 720/50p 720/59.94p 720/60p 1080/23.98p 1080/24p 1080/25p 1080/29.97p 1080/30p 1080/50i 1080/59.94i 1080/60i 1080/50p 1080/60P *1 NTSC-M, NTSC-433 *2 PAL-BDGHI, PAL-M, PAL-N, PAL-60 *3 3G-SDI signal *4 When a signal is changed 1080/23.98~30p to 1080/50i~60i (or vice versa), the input searches for a new timing by pressing the rotary knob.
  • Page 15: Pip / Pop / Pbp Function

    AMM215WTD 13 PIP / POP / PBP Function* The following combination options are available to you: Component / DVI 1 DVI 2 C-VIDEO Main RGBs DVI 1 DVI 2 Component/ RGBs C-VIDEO *When the frame frequency of the main screen is different from that of the sub screen, the picture may be disturbed.
  • Page 16: Ddc

    User’s Guide To make your installation easier, the monitor is able to Plug and Play with your system if your system also supports DDC protocol. The DDC (Display Data Channel) is a communication protocol through which the monitor automatically informs the host system about its capabilities, for example, supported resolutions and corresponding timing.
  • Page 17: Connecting The Power Cord

    AMM215WTD 15 Connecting the Power Cord * Check first to make sure that the power cord in use is the correct type required for the area. * This monitor has an universal AC adapter that allows operation in either AC 100 - 240 V ac voltage area. No user-adjustment is required.
  • Page 18: User Function / Messages

    User’s Guide User Functions / Messages Key Name and Function Power LED : Lights up to indicate the power is turned ON Standby Power Button: To power the monitor ON or OFF Rotary switch : With the OSD menu activated, increases the value of the selected (Turn Right) parameters or moves rightward in OSD menu Rotary switch : With the OSD menu activated, increases the value of the selected...
  • Page 19: Osd Section

    AMM215WTD 17 OSD Section Main Menu Chromatic Adjust Color Temp, Gamma Visual Adjust Brightness, Contrast, Phase, Chroma, Sharpness-V, Sharpness-H Setting Adjust Scale Mode, Color Space, Speaker Volume, Freeze Frame, Zoom / Pan, PIP, POP, PBP Advanced Adjust OSD Position Control, Screen Control, DPMS, Auto...
  • Page 20 User’s Guide OSD Section Chromatic Color Temp Change the Color Temperature - D65, D93, S1, S2 Gamma Change the Gamma Value - 1.8, 1.9, 1.95, 2.1, 2.1S, 2.2, 2.3, 2.4, 2.4S, S0, Radiograph Exit Exit the Menu Visual Brightness Adjust the Brightness of Panel (Range 0 - 100) Contrast Adjust the Contrast of Video (Range 0 - 100) Phase...
  • Page 21 AMM215WTD 19 OSD Section Setting Scale Mode Change the Scale Mode - Fill all, One to One, Vertical - Fill, Horizontal - Fill, Fill aspect ratio Color Space Change Color Space Between RGB and YPbPr Available for Component and RGBS...
  • Page 22 User’s Guide OSD Section Sub menu of PIP Mode PIP Mode ON / OFF Source PIP Sub Screen Source - DVI 1/2, HD/SD SDI, Component/RGBS, VGA, S-Video, C-Video Position PIP Sub Screen Position - Top L, Top R, Bottom L, Bottom R Size PIP Sub Screen Size - Small, Medium, Large Blending...
  • Page 23 AMM215WTD 21 OSD Section Sub menu of POP Mode POP Mode ON / OFF Source POP Sub Screen Source - DVI 1/2, HD/SD SDI, Component/RGBS, VGA, S-Video, C-Video Position POP Sub Screen Position - Top L, Top R, Bottom L, Bottom R...
  • Page 24 User’s Guide OSD Section Advanced OSD Position Change the OSD Menu - H and V Position Background, Control OSD Time Out, Language Screen Control Control and Adjust H and V position, Freqency, Phase Noise Reduction, Motion Offset DPMS Change the DPMS Auto Source Adjust Auto Source Select Between On and Off Select...
  • Page 25 AMM215WTD 23 OSD Section Sub Menu of OSD Control H-position Adjust OSD H - Position (Range 0 - 100) V-position Adjust OSD V - Position (Range 0 - 100) Back ground Adjust Transparency of OSD Background (Range 0 - 20)
  • Page 26 User’s Guide OSD Section Information Custom Entry Change the User or Monitor’s Name Display the Serial Number Runtime Display the Total Runtime Input Format Display the Current input Resolution and Vertical Frequency Exit Exit the Menu...
  • Page 27: Troubleshooting

    AMM215WTD 25 TROUBLESHOOTING Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. Problems Current Status Remedy No Picture Power LED ON · Using OSD, adjust brightness and contrast to maximum or reset to their default settings.
  • Page 28: Specifications Of (Amm215Wtd)

    User’s Guide Specification* Model AMM215WTD Description a-Si TFT Active Matrix, LED Backlight Active Screen Size 21.46 inches (545.22mm) diagonal Resolution 1920 (H) x 1080 (V) @60Hz Pixel Pitch 0.2475 mm Display Color 16.7M colors Color Tone Up to 256 color tone Response Time <25ms Typ.
  • Page 29: Classification

    CAN/CSA C22.2 NO. 601.1 Medical Equipment E215822 This monitor is intended for use in Health Care Facilities model AMM215WTD Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide.
  • Page 30: Electromagnetic Compatibility

    Consult the tables below for guidance in placing the AMM215WTD. Manufacturer’s declaration - electromagnetic emission The Model AMM215WTD is intended for use in the electromagnetic environment specified below. The customer or the user of AMM215WTD should assure that it is used in such an environment. Emission test Compliance...
  • Page 31 To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the AMM215WTD is used exceeds the applicable RF compliance level above, the AMM215WTD should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the AMM215WTD.
  • Page 32: Dimension Drawing (Mm) Of Ac Adapter

    Recommended Separation Distances Between Portable and Mobile RF Communications Equi- pement and the AMM215WTD System The AMM215WTD system is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the AMM215WTD system can help prevent electromagnetic...
  • Page 33: Dimension Drawing (Mm) Of Amm215Wtd

    AMM215WTD 31 Dimension Drawing (mm) of AMM215WTD Standby Power Button Power Switch...
  • Page 34: Connectors

    User’s Guide Connectors DC Input Connector Jack Power Input Description Description 13V Input 13 V Input Video Input 24 Pin DVI-I Connector. DDWG or Equivalent Connector. Description Description Description T.M.D.S. Data2- T.M.D.S. Data1- T.M.D.S. Data0- T.M.D.S. Data2+ T.M.D.S. Data1+ T.M.D.S. Data0+ T.M.D.S.
  • Page 35: Description Of Warranty

    BARCO standards, quality and specifications. Subject to the conditions and limitations set forth below, BARCO will, at its option, either repair any component of its products that prove defective by reason of improper workmanship or materials or BARCO has the exclusive right to replace with refurbished units or with an equivalent product.
  • Page 36 BARCO or its ASC without prior authorization. Buyer will be responsible for packaging (preferably original container) and shipping the defective goods to BARCO or its ASC, shipping charges prepaid. BARCO or its ASC will return the in warranty product, at no cost to the buyer.
  • Page 37 (out-of-warranty). Buyer must notify BARCO or its ASC of the defect and request an RMA number. If the configuration has been modified in any manner, the product must be returned to its original configuration before any service will be performed by BARCO or its ASC.
  • Page 38 ARE THE SOLE AND EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY OR ANY OTHER LEGAL THEORY. TO THE FULLEST EXTENT PERMITTED BY APPLICABLE LAW, BARCO SHALL NOT BE LIABLE TO THE PURCHASER OR END USER CUSTOMER OF AN BARCO PRODUCT FOR ANY DAMAGES,...
  • Page 39: Accessory Item List

    AMM215WTD 37 Accessory Item List Part Name Q’ty Description Remark AC- Adaptor Model Number: JMW1100KB1300F02 BridgePower Part Number: PS-52141209002E VGA Cable RGB 15P TO 15P, 1.8M, IVORY DVI cable DVI-I type CABLE 29P TO 29P BNC Cable BNC TO BNC ,1.8M/ RG58(JTC-15) S-Video Cable S-VIDEO W.2F/C/1.8M,BLACK...
  • Page 40 Barco, Inc. 1421 McCarthy Blvd. Milpitas, CA 95035,USA Tel : +1 408 400 4102 Fax : +1 408 400 4116 Web. Page : http://www.barco.com...
