ICP DAS USA PDS-220F Series Firmware Update

Via 7188xw.exe
Hide thumbs Also See for PDS-220F Series:
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
S
UPPORT
Models supported include
and PDS-220FCS-60
W
ARRANTY
All products manufactured by ICP DAS are warranted against
defective materials for a period of one year from the date of
delivery to the original purchaser.
W
ARNING
ICP DAS assumes no liability for damages consequent to the use
of this product. ICP DAS reserves the right to change this manual
at any time without notice. The information furnished by ICP
DAS is believed to be accurate and reliable. However, no
responsibility is assumed by ICP DAS for its use, nor for any
infringements of patents or other rights of third parties resulting
use.
from its
C
OPYRIGHT
Copyright © 2018 by ICP DAS. All rights are reserved.
T
RADEMARKS
Names are used for identification purposes only and may be
registered trademarks of their respective companies.
C
U
ONTACT
S
If you have any questions, please feel free to contact us. We will
respond within 2 working days.
Email:
service@icpdas.com ; service.icpdas@gmail.com
PDS-220FT, PDS-220FC, PDs-220FCS
PDS-220Fx Series
Firmware Update via 7188XW.exe
Version: 1.0/ Updated: Sep. 2018
Ch. 1. Setting up the PDS-220Fx
Ch. 2. Firmware Update Procedure
Ch. 3. Additional Information
ICP DAS CO., LTD.
Website: http://www.icpdas.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PDS-220F Series and is the answer not in the manual?

Questions and answers

Related Manuals for ICP DAS USA PDS-220F Series

Summary of Contents for ICP DAS USA PDS-220F Series

  • Page 1 PDS-220Fx Series UPPORT Models supported include PDS-220FT, PDS-220FC, PDs-220FCS Firmware Update via 7188XW.exe and PDS-220FCS-60 ARRANTY All products manufactured by ICP DAS are warranted against Version: 1.0/ Updated: Sep. 2018 defective materials for a period of one year from the date of delivery to the original purchaser.
  • Page 2 1. Setting up the PDS-220Fx Before updating the firmware, please ensure that the PDS-220Fx series module is connected with your host computer. Refer to the following steps for the details. Step 1: Switch off the Power to the PDS-200Fx module. Step 2: Connect the COM1 (RS-232) connector on PDS-220Fx to COM Port on host PC using CA-0910N cable.
  • Page 3 Step 4: Set the “SW1” to the “Init” position to initiate the update. Step 5: Power on (+12 ~ +48 V ) the PDS-200Fx module. Top Panel Power Supply Firmware Update via 7188XW.exe (Ver. 1.0/Sep. 2018) Page: 2...

  • Page 4: Firmware Update Procedure

    2. Firmware Update Procedure Step 1: Download the Firmware File of PDS-200Fx module and then decompress it to a temp folder, for example PDS220_fw_xxxxxx. Download the Firmware File. The PDS-220Fx firmware and autoexec.bat files are compressed in Zip format. You can decompress the zip file by 7-Zip, WinZip, WinRAR...
  • Page 5 Step 3: Double click the PDS-200Fx.bat for starting update. Double Click Step 4: You are now ready to update the firmware. The PDS-200Fx.bat file will auto run 7188XW.exe utility program and shows the progress of the update. Step 5: The 7188XW.exe utility program will then upload the firmware...
  • Page 6 Step 6: The Firmware update completed when disply [End file xxx] message. Then click “X” icon on the right-top corner of the windows to close it. Step 7: Set the “SW1” to the “Run” position. Step 8: Switch off the Power to the PDS-220Fx module and then switch it back on again to rebbot the module to “Run”...
  • Page 7 Step 9: Connect both the PDS-220Fx module and your computer to the same sub network or the same Ethernet Switch. Please refer to “Chapter 1- Connecting the Power and Host PC” in the PDS-200Fx Quick Start Guide. Download the Quick Start Guide. Step 10: Install the VxComm Utility your Host PC, and then run the Utility...
  • Page 8 Step 12: Click the name of the PDS-220Fx module. Step 13: Click the “Web” button. Step 14: Log in to the web configuration pages for the PDS-220Fx. Step 15: Verify that the firmware version and date details are correct. Firmware Update via 7188XW.exe (Ver. 1.0/Sep. 2018) Page: 7...

  • Page 9: Additional Information

    3. Additional Information Notes: Note 1: Make sure the 7188XW.exe and autoexec.bat program files exist on the same folder. If not, update firmware can’t be successful. …….…………………………………………………………….……………. back Note 2: If the IP address settings do not work correctly (e.g. there is no response to a ping command), please contact your network administrator to obtain a valid IP address for the PDS-220Fx module.
