CAUTION! Risk of Fire! DO NOT store instruction manuals inside fireplace cavity.
High temperatures could cause a fire.
INSTALLER: Leave this manual with the appliance, not inside the appliance.
CONSUMER: Retain this manual for future reference. Do not store inside the appliance.
NOTICE: DO NOT discard this manual!
ECHELON-C
SERIES
Models:
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
Majestic • ECHEL36IN-C/STIN-C, ECHEL48IN-C/STIN-C, ECHEL60IN-C, ECHEL72IN-C Installation Manual • 2608-980 Rev. D • 9/19
Installation Manual
Installation and Appliance Setup
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
Decorative barrier front must be ordered separately at
time of appliance purchase. See Section 3.A.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1
Advertisement
Table of Contents
Related Manuals for Hearth & Home ECHELON-C Series
Summary of Contents for Hearth & Home ECHELON-C Series
- Page 1 Installation Manual Installation and Appliance Setup CAUTION! Risk of Fire! DO NOT store instruction manuals inside fireplace cavity. High temperatures could cause a fire. INSTALLER: Leave this manual with the appliance, not inside the appliance. CONSUMER: Retain this manual for future reference. Do not store inside the appliance. NOTICE: DO NOT discard this manual! WARNING: FIRE OR EXPLOSION HAZARD...
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... -
Page 3: Installation Standard Work Checklist
Installation Standard Work Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. Customer: Date Installed: Lot/Address: Location of Fireplace: Installer: Model Dealer/Distributor Phone #... -
Page 4: Product Specific And Important Safety Information
Product Specific and Important Safety Information A. Appliance Certification C. BTU Specifications Minimum Orifice MODEL: ECHEL36IN-C ECHEL36STIN-C Models Maximum Input Size Input BTU/h (U.S. or Canada) ECHEL48IN-C ECHEL48STIN-C BTU/h (DMS) ECHEL60IN-C ECHEL72IN-C ECHEL36IN-C (0-2000 FT) 30,000 17,500 (NG) LABORATORY: Underwriters Laboratories, Inc. (UL) ECHEL36IN-C TYPE: Direct Vent Heater (0-2000 FT) -
Page 5: Non-Combustible Materials Specification
E. Non-Combustible Materials Specification Material which will not ignite and burn. Such materials are those consisting entirely of steel, iron, brick, tile, concrete, slate, glass or plasters, or any combination thereof. Materials that are reported as passing ASTM E 136, Standard Test Method for Behavior of Materials in a Vertical Tube Furnace at 750 ºC shall be considered non-combustible materials. -
Page 6: Requirements For The Commonwealth Of Massachusetts
Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed I. -
Page 7: Getting Started
Getting Started A. Design and Installation Considerations WARNING! Risk of Fire or Explosion! Read all instruc- tions before starting the installation. Majestic direct vent gas appliances are designed to oper- ate with all combustion air siphoned from outside of the building and all exhaust gases expelled to the outside. -
Page 8: Good Faith Wall Surface
B. Good Faith Wall Surface OPTIONAL PASSIVE HEAT KIT INSTALLED FIREPLACE The ECHELON-C models may be installed with or without OPENING optional heat management systems, including the Pas- sive Heat kit. The installation of a heat management sys- tem will affect certain aspects of the appliance installation including framing dimensions and clearances to combus- 95°F tibles. -
Page 9: Tools And Supplies Needed
C. Tools and Supplies Needed D. Inspect Appliance and Components Before beginning the installation be sure that the following WARNING! Risk of Fire or Explosion! Damaged parts tools and building supplies are available. could impair safe operation. DO NOT install damaged, in- complete or substitute components. -
Page 10: Framing And Clearances
Framing and Clearances A. Appliance/Decorative Barrier Front Dimension Diagrams Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5. HEAT MANAGEMENT SYSTEMS KNOCKOUTS IMPORTANT: Must use appropriate knockout(s) for the selected Heat Management System. - Page 11 HEAT MANAGEMENT SYSTEMS KNOCKOUTS IMPORTANT: Must use appropriate knockout(s) for the selected Heat Management System. See Section 6. CENTERED ON APPLIANCE ELECTRICAL ACCESS GAS ACCESS ECHEL60IN-C ECHEL72IN-C ECHEL60IN-C ECHEL72IN-C Location Location Inches Millimeters Inches Millimeters Inches Millimeters Inches Millimeters 1880 2184 63-1/8 1603...
- Page 12 HEAT MANAGEMENT SYSTEMS KNOCKOUTS IMPORTANT: Must use appropriate knockout(s) for the selected Heat Management System. See Section 6. CENTERED ON APPLIANCE ELECTRICAL ACCESS GAS ACCESS ECHEL36STIN-C ECHEL48STIN-C ECHEL36STIN-C ECHEL48STIN-C Location Location Inches Millimeters Inches Millimeters Inches Millimeters Inches Millimeters 1270 1575 39-1/4 51-1/8...
- Page 13 PFF DECORATIVE FRONT Note: See Section 10 for hearth, mantel and finishing requirements. Barrier Mesh: Integral to Decorative Barrier Front ECHEL36IN-C ECHEL48IN-C ECHEL60IN-C ECHEL36STIN-C ECHEL48STIN-C Location Inches Millimeters Inches Millimeters Inches Millimeters 37-1/4 49-1/4 1250 61-1/4 1556 13-1/8 13-1/8 13-1/8 1194 1498 1803...
- Page 14 Note: See Section 10 for CLEAN FACE TRIM DECORATIVE BARRIER FRONT hearth, mantel and finishing requirements. Barrier Mesh: Integral to Decorative Barrier Front ECHEL36IN-C ECHEL48IN-C ECHEL60IN-C ECHEL72IN-C ECHEL36STIN-C ECHEL48STIN-C Location Inches Millimeters Inches Millimeters Inches Millimeters Inches Millimeters 1295 1600 1905 16-3/4 16-3/4...
-
Page 15: Appliance Location And Clearances To Combustibles
B. Appliance Location and Clearances to NOTICE: Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams Combustibles are not drawn to scale. Actual installation may vary due to When selecting a location for the appliance it is important individual design preference. - Page 16 NOTICE: This See-Through appliance is NOT designed or approved for an indoor/outdoor application. MODEL Inches 48-1/4 17-1/8 ECHEL36STIN-C Millimeters 1226 1219 Inches 60-1/4 17-1/8 ECHEL48STIN-C Millimeters 1530 1219 Figure 3.7 Appliance Locations: ECHELON-C See-Through Models Majestic • ECHEL36IN-C/STIN-C, ECHEL48IN-C/STIN-C, ECHEL60IN-C, ECHEL72IN-C Installation Manual • 2608-980 Rev. D • 9/19...
- Page 17 HEADER DEPTH** NOTE: E & K dimensions will change if Passive Heat option is installed. Reference the instructions APPLIANCE MAY BE INSTALLED OFF OF FLOOR*** included with the Passive Heat Kit for dimensions. MINIMUM FRAMING DIMENSIONS* ECHEL36IN-C Rough Rough Rough Rough Clearance Combustible...
- Page 18 E=MEASUREMENT FROM TOP OF FIREPLACE OPENING TO CEILING J=MEASUREMENT FROM BOTTOM OF FIREPLACE TO CEILING HEADER DEPTH** HEADER DEPTH** NOTE: E & J dimensions will change if APPLIANCE MAY BE INSTALLED OFF OF FLOOR*** Passive Heat option is installed. Reference the instructions included with the Passive Heat Kit for dimensions.
-
Page 19: Constructing The Appliance Chase
C. Constructing the Appliance Chase NOTICE: Install appliance on hard metal or wood surfaces extending full width and depth. DO NOT install directly on carpeting, vinyl, or any combustible material other than wood. WARNING! Risk of Fire! Maintain specified air space clearances to appliance and vent pipe: •... -
Page 20: Floor Protection
D. Floor Protection NOTICE: Install appliance on hard metal or wood surfaces extending full width and depth. DO NOT install directly on carpeting, vinyl, tile or any combustible material other than wood. WARNING! Risk of Fire! Maintain specified air space clearances to appliance and vent pipe: •... -
Page 21: Termination Location And Vent Information
Termination Location and Vent Information A. Approved Pipe WARNING! Risk of Fire, Delayed Ignition or Asphyxi- 6 in. (minimum) up to 20 in. 18 in. minimum ation. This appliance requires a separate vent. DO NOT 152 mm/508 mm 457 mm vent to a pipe serving any other appliance. -
Page 22: Vent Terminal Clearances
C. Vent Terminal Clearances = AREA WHERE TERMINAL IS NOT PERMITTED = AIR SUPPLY INLET = VENT TERMINAL Electrical Service H or i U.S.A. Installations: In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code. Canadian Installations: In accordance with the current CSA B149.1, Natural Gas and Propane Installation Code. U.S.A. -
Page 23: Use Of Elbows
D. Use of Elbows Diagonal runs have both vertical and horizontal vent as- pects when calculating the effects. Use the rise for the vertical aspect and the run for the horizontal aspect. See Figure 4.5. Two 45º elbows may be used in place of one 90º elbow. On 45º... -
Page 24: Vent Diagrams
E. Vent Diagrams Measuring Standards: Vertical and horizontal measurements listed in the vent General Rules: diagrams and clearances for termination were made • SUBTRACT 3 ft from the total H measurement for each using the following standards: 90º elbow installed horizontally. •... - Page 25 OVERHANG WALL C and E dimensions are defined in Figure 4.4. Figure 4.10 Measure Horizontal and Vertical Termination Clearance to Trapezoid Portion of Cap Majestic • ECHEL36IN-C/STIN-C, ECHEL48IN-C/STIN-C, ECHEL60IN-C, ECHEL72IN-C Installation Manual • 2608-980 Rev. D • 9/19...
- Page 26 WARNING Fire Risk. Explosion Risk. Do NOT pack insulation or other combustibles between ceiling firestops. • ALWAYS maintain specified clearances around venting and firestop systems. • Install wall shield and ceiling firestops as specified. Failure to keep insulation or other material away from vent pipe could cause fire. Top Vent - Horizontal Termination Venting with 1 elbow WARNING! Risk of Fire! DO NOT attach elbow directly to the appliance.
- Page 27 Top Vent - Horizontal Termination Venting with 2 elbows WARNING! Risk of Fire! DO NOT attach elbow directly to the appliance. • The ECHEL36IN-C/ECHEL36STIN-C, ECHEL48IN-C/ECHEL48STIN-C and ECHEL60IN-C require a minimum of 18 inches of vertical venting before attaching any elbow to the appliance. •...
- Page 28 Top Vent - Horizontal Termination Venting with 3 Elbows WARNING! Risk of Fire! DO NOT attach elbow directly to the appliance. • The ECHEL36IN-C/ECHEL36STIN-C, ECHEL48IN-C/ECHEL48STIN-C and ECHEL60IN-C require a minimum of 18 inches of vertical venting before attaching any elbow to the appliance. •...
- Page 29 Top Vent - Vertical Termination No Elbows V = 2-1/2 ft Min. (762 mm), 50 ft. Max. (15.2 m) Note: If installing a vertical vent/termination off the top of the appliance, the optional exhaust restrictor may be needed. Note: Use DVP Series components only.
- Page 30 Exhaust restrictor Instructions Exhaust restrictors are recommended for these vertically PILOT terminated products which have excessive draft. Exhaust HOLES restrictors will compensate for high draft, and restore vi- sual flame height. If the vent configuration has a total vertical of 20-50 feet, the included exhaust restrictor may be needed.
- Page 31 Top Vent - Vertical Termination Venting with 2 elbows WARNING! Risk of Fire! DO NOT attach elbow directly to the appliance. • The ECHEL36IN-C/ECHEL36STIN-C, ECHEL48IN-C/ECHEL48STIN-C and ECHEL60IN-C require a minimum of 18 inches of vertical venting before attaching any elbow to the appliance. •...
- Page 32 Top Vent - Vertical Termination Venting with 3 elbows WARNING! Risk of Fire! DO NOT attach elbow directly to the appliance. • The ECHEL36IN-C/ECHEL36STIN-C, ECHEL48IN-C/ECHEL48STIN-C and ECHEL60IN-C require a minimum of 18 inches of vertical venting before attaching any elbow to the appliance. •...
-
Page 33: Vent Clearances And Vent Framing
Vent Clearances and Vent Framing A. Vent Clearances to Combustibles WARNING! Risk of Fire! Maintain air space clearance to vent. DO NOT pack insulation or other combustibles: • Between ceiling firestops • Between wall shield firestops • Around vent system Failure to keep insulation or other material away from vent pipe could cause overheating and fire. -
Page 34: Wall Penetration Framing/Firestops
B. Wall Penetration Framing/Firestops DO NOT PACK VENT FRAMING HOLE WITH INSULATION Combustible Wall Penetration OR OTHER MATERIAL. Whenever a combustible wall is penetrated, you must frame a hole for the wall shield firestop(s). The wall shield firestop maintains minimum clearances and prevents cold air infiltration. -
Page 35: Ceiling Firestop/Floor Penetration Framing
C. Ceiling Firestop/Floor Penetra- tion Framing WARNING! Risk of Fire! DO NOT pack insu- lation around the vent. Maintain clearances to vent to prevent overheating. ATTIC ABOVE A ceiling firestop MUST be used between floors and attics. • DVP pipe only - Frame an opening 10 in. by 10 in. -
Page 36: Appliance Preparation
Appliance Preparation CAUTION! Risk of Cuts, Abrasions or Flying Debris. Wear protective gloves and safety glasses during LOCATION FOR INSTALLATION OF FIBERGLASS ROPE RING installation. Sheet metal edges are sharp. A. Top Standoff Preparation 1. Rotate the four (4) top standoffs up into vertical position. 60 and 72 only: Push the standoff support tab on each standoff toward the center of the appliance and fasten it in place using the supplied screw and pilot hole. -
Page 37: Prepare For Heat Management
B. Prepare For Heat Management WARNING! Risk of Fire! DO NOT remove heat management seal plate unless a heat management Introduction System will be connected at that location. Overheating of appliance and combustible materials will occur. An optional heat management system allows the heat from the appliance to be redirected as desired. -
Page 38: Securing And Leveling The Appliance
C. Securing and Leveling the Appliance Securing and Leveling the Appliance Setting the Fireplace into the Framing WARNING The left and right nailing tabs were designed as a means Risk of Fire! to ensure the fireplace is mounted flush with the framing materials. -
Page 39: Installing Non-Combustible Facing Material
D. Installing Non-Combustible Facing Material WARNING! Risk of Fire! • Follow these instructions exactly. • Facing materials must be installed properly to prevent fire. • No materials may be substituted without authorization by Hearth & Home Technologies. • Remove protective cardboard sleeve from non- combustible facing pieces, which are included with the appliance. -
Page 40: Venting
Venting Assemble Pipe Sections A. Assemble Vent Sections (DVP Pipe Only) Per Figure 7.2: WARNING! Risk of Fire or Explosion! Vent sections • Start the inner pipe on the lanced end of section A into MUST be installed correctly. Improperly installed vent the flared end of section B. - Page 41 NOTICE: When installing a vent system with an HRC termination cap, all pipe system joints shall be sealed using a high temperature silicone sealant (300 ºF minimum continuous exposure rating). • Apply a bead of silicone sealant (300 ºF minimum continuous exposure rating) inside the female outer pipe joint prior to joining sections.
-
Page 42: Assemble Slip Sections
B. Assemble Slip Sections C. Secure the Vent Sections • Slide the inner flue of the slip section into the inner flue WARNING! Risk of Fire, Explosion or Asphyxiation! of the pipe section and the outer flue of the slip section Improper support could allow vent to sag and separate. -
Page 43: Disassemble Vent Sections
D. Disassemble Vent Sections • Rotate either section (see Figure 7.9) so the seams on both pipe sections are aligned as shown in Figure 7.10. • Pull carefully to separate the pieces of pipe. Figure 7.9 Rotate Seams for Disassembly Figure 7.10 Align and Disassemble Vent Sections Majestic •... -
Page 44: Vertical Termination Requirements
E. Vertical Termination Requirements Assemble and Install Storm Collar CAUTION! Risk of Cuts, Abrasions or Flying Debris. Install and Seal Metal Roof Flashing Wear protective gloves and safety glasses during instal- • See minimum vent heights for various pitched roofs lation. -
Page 45: Horizontal Termination Requirements
Install Vertical Termination Cap F. Horizontal Termination Requirements • Attach the vertical termination cap by sliding the inner Heat Shield Requirements for Horizontal collar of the cap into the inner flue of the pipe section Termination while placing the outer collar of the cap over the outer WARNING! Risk of Fire! To prevent overheating and fire, flue of the pipe section. - Page 46 Install Horizontal Termination Cap (DVP and SLP Pipe) HEAT SHIELD OR HEAT SHIELD EXTENDED WARNING! Risk of Fire! The telescoping flue section of 1-1/2 IN. (38 MM) MIN. HEAT SHIELD OVERLAP WALL SHIELD the termination cap MUST be used when connecting vent. FIRESTOP •...
-
Page 47: Electrical Information
Electrical Information A. General Information WARNING! Risk of Shock! DO NOT wire 110-120 VAC to the ignition module or to the appliance wall switch. (IPI) Incorrect wiring will damage controls. NOTICE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA 70-latest edition or the Canadian Electric Code CSA C22.1. - Page 48 Junction Box Installation 5. Route the wire through the strain relief in the outer wrap and up through the cutout located on the metal WARNING! Risk of Shock! Label all wires prior to dis- tray under the junction box. connection when servicing controls. Wiring errors can 6.
-
Page 49: Wiring Requirements
B. Wiring Requirements Accessories Requirements IntelliFire™ Touch Ignition System Wiring • This appliance ships standard with a remote control. Wiring for optional Hearth & Home Technologies approved • Wire the appliance junction box to 110-120 VAC for accessories should be done now to avoid reconstruction. proper operation of the appliance. - Page 50 6 VAC TRANSFORMER FLAME IFT-RC400 IGNITER SENSE RESET SWITCH REMOTE 2206-298 CONTROL JUNCTION BOX 110-120 VAC RESET SWITCH WIRE 2550-135 JUMPER WIRE SEE DETAIL A DETAIL A JUMPER WIRE TO JUNCTION BOX 110-120 VAC RF MODULE BLUE WHITE BLACK BLACK DIMMER JUNCTION BOX 110VAC...
-
Page 51: Gas Information
Gas Information A. Fuel Conversion Note: Have the gas supply line installed in accordance with local codes, if any. If not, follow ANSI Z223.1. Installation • Make sure the appliance is compatible with available gas should be done by a qualified installer approved and/or types. - Page 52 3. Unplug the 6V transformer from the junction box. This will turn the power off to the appliance. 4. Turn the gas shutoff handle to the “OFF” position to shut off the gas supply. If additional access is needed, proceed as follows: 5.
-
Page 53: Gas Connection
D. Gas Connection E. High Altitude Installations • Refer to Reference Section 3 for location of gas line NOTICE: If the heating value of the gas has been reduced, access in appliance. these rules do not apply. Check with your local gas utility or authorities having jurisdiction. -
Page 54: Air Shutter Setting
F. Air Shutter Setting Air Shutter Settings ECHEL36IN-C WARNING! Risk of Explosion or Delayed Ignition! ECHEL36STIN-C Improperly adjusted air shutter could cause soot buildup. Propane ECHEL48IN-C NOTICE: If sooting occurs, provide more air by opening ECHEL48STIN-C the air shutter. Standard Standard GLASS REFRACTORY Air shutter settings may be adjusted by a qualified install-... -
Page 55: Finishing
Finishing A. Facing Material Finishing Instructions It is important to follow the framing and finishing instruc- WARNING tions to ensure proper placement of fireplace into the sur- rounding framing/finishing materials. Risk of Fire! Wall sheathing materials 1/2 in. thick are specified in this installation manual to properly align with the factory- DO NOT apply combustible materials beyond the min- included non-combustible material. - Page 56 This section discusses installation details associated Finish and Sealing Joints with the Inside and Overlap Fit methods and specifies All joints between the finished wall sheathing and the ap- additional non-combustible materials required. pliance must be sealed with non-combustible materials. Sealants, such as caulk or mastic used to seal the gap When finishing the wall around the fireplace, it is critical between the wall and the fireplace, should be rated at a...
- Page 57 NOTICE: The location of the Passive Heat discharge opening could allow for venting and other construction materials to be visible. It is acceptable to paint the vent pipe and other construction materials using a high temperature paint with a minimum of 300 °F continuous exposure rating. 1/2 IN.
- Page 58 1/2 IN. THICK WALL SHEATHING NON-COMBUSTIBLE NON-COMBUSTIBLE FINISHING MATERIAL FINISHING MATERIAL 1/2 IN. OVERLAP FIT = 0-1 IN. THICK OVERLAP FIT = 0-1 IN. THICK INSTALLED NON-COMBUSTIBLE INSIDE FIT = 1-4 IN. THICK INSIDE FIT = 1-4 IN. THICK BOARD FINISHING FINISHING GUARDS...
-
Page 59: Decorative Barrier Fronts
B. Decorative Barrier Fronts Note: When a Clean Face Trim decorative barrier front is installed, the rectangular holes in bottom access panel WARNING! Risk of Burns! A decorative barrier front is will be covered. required for this model. DO NOT operate this appliance without a decorative barrier front in place. - Page 60 Clean Face Trim Front (CFT) With Decorative Trim Ring: (Option #2) The trim ring, which is included with the CFT front, will be Inside Fit (1-4 Inches Thick Finishing Method) installed and used as a finishing template. It will be left exposed.
- Page 61 Finishing - Raised Hearth in Front of Appliance A non-combustible hearth may be installed in front of the appliance only if the inside fit finishing method with CFT doors is used. TRIM RING INSTALLED 1. Non-combustible hearth material may be placed up to the bottom edge of the trim ring.
- Page 62 Picture Frame Front (PFF) Overlap Fit (0-1 Inch Thick Finishing Material Only) Non-Combustible Finish Materials Decorative Front Finishing Method Material Thickness Trim Ring Picture Frame Front (PFF) Overlap Fit 0-1 inch Not included Picture Frame Front (PFF) Inside Fit Not included WARNING! Risk of Fire! DO NOT apply combustible WARNING! Risk of Fire! DO NOT apply finishing mate- materials beyond the minimum clearances.
- Page 63 0-4 Inch Thickness-Inside Fit Method 0-4 Inches Finishing (Inside Fit): See Figure 10.10 the required measurements to ensure the proper fit of the PFF. The top and bottom will have a 1/2 inch space from the PFF to the finished wall above and below it.
-
Page 64: Mantel And Wall Projections
C. Mantel and Wall Projections TO CEILING Note: All measurements in inches. WARNING! Risk of Fire! Comply with all minimum clear- ances to combustibles as specified. Framing closer than the MAX. minimums listed must be constructed entirely of noncom- bustible materials (i.e., steel studs, concrete board, etc.) If the Passive Heat kit will be installed, see Figure 10.18 for details regarding clearances to combustibles in addi- tion to the requirements for Combustible and Non-Com-... - Page 65 Non-Combustible Mantels INSIDE FIT OVERLAP FIT Note: All measurements in inches. Note: All measurements in inches. TO CEILING MAX. TO CEILING 14-16 MAX. 31 MIN. 13-16 MIN. MEASUREMENTS FROM TOP EDGE MEASUREMENTS FROM TOP EDGE OF THE APPLIANCE OPENING OF THE APPLIANCE OPENING Measurement from top edge of opening Measurement from top edge of opening to bottom of appliance = 24-1/2 IN.
- Page 66 Clearances with Passive Heat Optional Heat Management System Figure 10.19 shows the required clearances for appliance, ceiling finishing material and framing members. Ensure all clearances are maintained. Good Faith Guidelines for TV Installations Above a ECHELON-C Fireplace with Passive Heat Option (Single-Sided Appliance Shown) WARNING! Risk of Fire! Wire mesh required on bottom of discharge opening when discharge...
-
Page 67: Appliance Setup
Appliance Setup A. Fixed Glass Assembly Removal and Re- B. Remove the Shipping Materials/Install Bottom Glass Shield placement Remove shipping materials from inside or underneath WARNING! Risk of Asphyxiation! Handle fixed glass the firebox. Verify all components are with the fireplace. assembly with care. -
Page 68: Clean The Appliance
C. Clean the Appliance F. Install Media (Included) Clean/vacuum any sawdust that may have accumulated A media kit is included for use with the ECHELON mod- inside the firebox or underneath in the control cavity. els. Install glass media as instructed. Use the chart below to determine the amount of media to use for the model size being installed. - Page 69 INSTALLATION WARNING CAUTION! Risk of Burns! The fireplace should be turned Risk of Asphyxiation or Fumes. off and cooled before media is installed. • Place media according to instructions. • Do NOT place media in area between glass and Note: If both the media and logs will be installed, the logs firebox.
- Page 70 6. Place the media set aside in Step 1 over the pilot shield and areas shown in Figure 4 uncovered by NO MEDIA ALLOWED removing the media placement jig. See Figure 4. DO NOT allow any media in the 1 inch area shown in Figure 5.
-
Page 71: Intellifire™ Touch Control System Setup
G. IntelliFire™ Touch Control System Setup • Detailed instructions electrical wiring connections are provided in Section 8. • Determine if this appliance is equipped with a Module Reset Switch. See Section 8. Verify this switch is in the ON position. •... -
Page 72: Reference Materials
Reference Materials A. Vent Components Diagrams Effective Length Pipe Inches Millimeters 10-1/2 in. (267 mm) DVP4 45 ° Effective Height/Length DVP6 DVP12 4-7/8 in. DVP24 (124 mm) 10-7/8 in. DVP36 (276 mm) DVP Pipe (see chart) DVP48 1219 DVP45 (45º Elbow) DVP6A 3 to 6 76 to 152... - Page 73 A. Vent Components Diagrams (continued) Note: Heat shields MUST overlap by a minimum of 1-1/2 in. (38 mm). The heat shield is designed to be used on a wall 4 in. to 7-1/4 in. (102 mm to 184 mm) thick. If wall thickness is less than 4 in. (102 mm) the existing heat shields must be field trimmed.
- Page 74 A. Vent Components Diagrams (continued) 31 in. (787 mm) 13-1/4 in. (337 mm) 24-5/8 in. (625 mm) 27-1/2 in. 24-5/8 in. (699 mm) (625 mm) 13-1/4 in. (337 mm) RF12 Roof Flashing Roof Flashing 11-7/8 in. 5 in. (302 mm) (127 mm) 7 IN.
- Page 75 A. Vent Components Diagrams (continued) 7-3/8 in. (187 mm) 1-1/2 in. (38 mm) 12 in. 305 mm 14 in. 17-3/4 in. (356 mm) (451 mm) 7-1/4 in. 6 in. (184 mm) 152 mm 12-1/2 in. (318 mm) 5-1/4 in. 12 in. (133 mm) (305 mm) DVP-TB1...
- Page 76 Optional Wire Harness 13-5/8 IN. 346 mm DESCRIPTION PART NUMBER EFFECTIVE LENGTH 32 IN. (813 mm) MIN. 10 FT PV Wire Harness PVI-WH10 35 IN. (889 mm) MAX. 20 FT PV Wire Harness PVI-WH20 40 FT PV Wire Harness PVI-WH40 12-1/2 IN.
- Page 77 A. Vent Components Diagrams (continued) Top View 6-1/4 IN. 159 mm 1-1/2 IN. 38 mm Front View Side View 2-1/4 IN. 15-1/2 IN. 57 mm 394 mm 4-3/4 IN. 121 mm 8 IN. 14 IN. 9-1/2 IN. 203 mm 356 mm 241 mm 5-1/4 IN.
-
Page 78: Accessories
Optional Heat Management Systems Kits B. Accessories Install approved accessories per instructions included After a qualified service technician has installed the heat with accessories. Contact your dealer for a list of ap- management system, follow the instructions supplied with proved accessories. the kit for operation.
