General Information
bar top and bar rail by others
(Shown for Reference Only)
The underside of
the bar top should have a flat
single plane.
a) After all other steps have been completed, place
the assembled bar top in position.
note: If bar layout includes a Model 8000 ice
cream unit, place into module before
installing top.
b) Fasten top to bar structure using #10 x 1/2" long
round head screws.
Form No. Z22162
Rev. 06.12.10
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice.

soda Guns

Soda gun locations should be predetermined so the
factory can provide an opening for soda hoses.
a) Wunderbar brand soda hose manifolds can be
attached to the underside of the bar top
in front of filler strip, taking into consideration any
underbar lighting which may be present.
b) Six inch stainless steel Manifold Housing for
Concealing Soda Manifold. Installs on TS6CO.
Accessory Part #7055-66SG.
