  • Page 1 ESA5000 V1.0...
  • Page 2 GoodWe Smart Hybrid Inverter ESA5000 Installation Manual © 2019 by GoodWe. All rights Reserved. This work is copyright, apart from any use permitted under the Copyright Act 1968. No part may be reproduced by any process, nor may any other exclusive right be exercised without the permission of GoodWe.
  • Page 3 General mode Off grid mode Standby mode Economic mode...
  • Page 4 6. GoodWe Smart Hybrid Inverter internet connection Wi-Fi configuation PV Master APP operation CEI Auto-test function 10 Checklist...
  • Page 5 GoodWe. (for example VDE-AR-N 4105 in Germany). GoodWe...
  • Page 7 GoodWe...
  • Page 8 GoodWe technical GoodWe Smart Hybrid...
  • Page 9 GoodWe...
  • Page 10 GoodWe Smart Hybrid Inverter includes all of the following functions,components and features in an single easy-to-install product.

  • Page 11: Lithium-Ion

    4600W AC 4600W AC ℃ 22.8A AC 40A AC 180 to 270V AC, Less than 3% 0.8 leading to 0.8 lagging (adjustable) Category Integrated Transformerless (with HF transformer isolation for battery) 48V DC Lithium-ion 4600W DC 85A DC 100A DC BMS controlled 57.0V DC Integrated 2 pole DC breaker 125A DC per pole...
  • Page 13 ESA5000 ESA5000 ESA5000 ESA5000...
  • Page 15 The GoodWe Smart Hybrid Inverter can provide up to 5000 Watts of continuous AC power for AC loads,which are connected to the backup loads.The system can provide a maximum of 6900 Watts of AC power for up to 10 seconds to start loads,which require a higher amount of power initially.The output of the Inverter is reduced if the ambient temperature exceeds 45℃...

  • Page 16: General Mode

    There are four working modes for GoodWe Smart Hybrid Inverter ： general mode (default), off-grid mode, standby mode and economic mode, which can be set by APP or port. General mode General mode:In this mode, the power generated by photovoltaic gives priority to the load power supply, the remaining power charges the battery, if the power is still remaining ，...

  • Page 17: Off Grid Mode

    If there is no grid power, it is priority that PV supplies power to the load, when the energy provided by the PV is insufficient, then the battery provided. 2.2.2 Off grid mode Off grid mode: Photovoltaic and battery constitute a pure off-grid system, suitable for non-grid areas. 2.2.3 Standby mode Standby mode: Battery discharges only in abnormal condition of grid, similar to uninterrupted power...
  • Page 18 GoodWe Smart Hybrid Battery Enclosure BCL0096 Use appropriate fasteners to secure the GoodWe Smart Hybrid Inverter mounting plate to the mounting surface.GoodWe will not be responsible for damage to the product if it is attached with inadequate fasteners. GoodWe GoodWe...
  • Page 19 Figure 6 Figure 8 Figure 7 Figure 7：Mounting the Inverter Figure 6：Mounting the BOS...
  • Page 20 GoodWe Smart Hybrid Inverter. GoodWe Smart Hybrid Inverter...
  • Page 22 Screw up PV isolator Utility grid Battery 40 amp 400Vac 125 amp per pole80/125VDC Backup 2-pole circuit breaker 2-pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker WI-FI switch board Earth terminals Manual AC load 25 amp 250Vac bypass switch RS485...
  • Page 23 PV isolator Utility grid Battery 40 amp 400Vac 125 amp per pole80/125VDC Backup 2-pole circuit breaker 2-pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker WI-FI switch board Manual AC load 25 amp 250Vac bypass switch...
  • Page 24 standards(like VDE-AR-N 4105 in Germany）.
  • Page 25 PV isolator Utility grid Battery 40 amp 400Vac 125 amp per pole80/125VDC Backup 2-pole circuit breaker 2-pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker WI-FI switch board Earth terminals Manual AC load 25 amp 250Vac bypass switch...
  • Page 26 RS485...
  • Page 27 PV isolator Utility grid Battery 40 amp 400Vac 125 amp per pole80/125VDC Backup 2-pole circuit breaker 2-pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker WI-FI switch board Earth terminals Manual AC load 25 amp 250Vac bypass switch...
  • Page 28 GoodWe Smart Hybrid Inverter...
  • Page 29 PV isolator Utility grid Battery 40 amp 400Vac 125 amp per pole80/125VDC Backup 2-pole circuit breaker 2-pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker WI-FI switch board Earth terminals Manual AC load 25 amp 250Vac bypass switch Figure 16：AC terminals...
  • Page 30 PV isolator Utility grid Battery 40 amp 400Vac 125 amp per pole80/125VDC Backup 2-pole circuit breaker 2-pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker WI-FI switch board Earth terminals Manual AC load 25 amp 250Vac bypass switch...
  • Page 31 GoodWe Smart Hybrid Inverter. PV isolator Utility grid Battery 40 amp 400Vac 125 amp per pole80/125VDC Backup 2-pole circuit breaker 2-pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker WI-FI switch board Earth terminals Manual AC load 25 amp 250Vac...
  • Page 32 The utility grid energy meter is used to measure the amount of energy which is flowing from or to the utility grid,and to allow the GoodWe Smart Hybrid Inverter to limit or restrict power flow back into the utility grid by adjusting the amount of power being supplied form the solar array and the battery.
  • Page 33 Backup 2-pole circuit breaker -pole circuit breaker Earth 25 amp 400Vac 2-pole circuit breaker h board Grid main Manual AC load 230V utility grid 25 amp 250Vac connection terminals bypass switch bottom bottom GoodWe Smart Hybrid Inverter...
  • Page 34 Backup...
  • Page 35 GoodWe...
  • Page 36 GoodWe...

  • Page 38: Led Indicators

    LED indicators...
  • Page 39 6. GoodWe Smart Hybrid Inverter internet connection 6.1 Wi-Fi configuation www.semsportal.com...

  • Page 40: Pv Master App Operation

    2. If everything is right well, the Wi-Fi LED on inverter will change from double blink to quartic blink then to solid status, which means Wi-Fi is connected to GoodWe icloud successfully. 3. Wi-Fi configuration could also be done on PV Master, details please check on PV Master APP.
  • Page 41 GoodWe...
  • Page 42 VDE-AR-N 4105...
  • Page 44 GoodWe PV Master APP. GoodWe portal www.goodwe.com. www.good we.com.
  • Page 45 340-00296-00...
