(866) 433-6682 • (281) 359-8538 • sales@novatech-usa.com • www.novatech-usa.com
11.5 Cycle Timer Menu
From this menu configure how often and the duration you want the timer to run for. The cycle
timer is very similar to the 28 day timer
Home Screen
Settings
On Time – Sets the duration that the timer will activate the output for.
Off Time – Sets the duration that the timer will deactivate the output for.
# Cycles - Set the number of times the timer will repeat the on and off times at the start
time setting described below.
Start Times – Set up to four start times. Setting the value to 00:00 means the start time
is ignored. Set the days and weeks you want the timer to run for. See the next section
for details on how to set the days and weeks.
11.6 Cycle Timer Menu – Start Times
From this menu configure the days and weeks the timer will run for. Any combination of days
and/or weeks is acceptable for each timer.
Home Screen
Settings
ALL | SUN| MON| TUE
WED| THU| FRI | SAT
Days
Cancel
- Select the timer start days and weeks by using the up and down buttons to the right of
the display. Move the cursor to the right or left by using the button to the bottom of the
display. The selected day or week will flash as the cursor is moved to each setting. The
flashing On|Off text indicates if the current setting is on or off.
- If a day or week is highlighted, or appears as reverse video, that particular day or week
will have biocide feed.
- The week # shown in the lower right of the display indicates which week number the
controller's time is currently set to.
72-910-23 Rev.F
Page 24 of 30
Timer 1
Cycle Timer
Timer 1
On|Off
|
Enter
Cycle Timer
ALL | EVN| ODD| 1ST
2ND | 3RD| 4TH |
Weeks On|Off Wk#2
Cancel
|
Enter
On Time
Off Time
# Cycles
Start Times
Back | Select
Start times
Start time 1
Start Time 1
hh:mm
01:00A
Cancel
|
Enter
