OP 3 – The amount of time, in hours, the Timer 3 output was energized since it was last
reset.
OP 4 – The amount of time, in hours, the Timer 4 output was energized since it was last
reset.
OP 5 – The amount of time, in hours, that the dry contact relay 5 was energized since it
was last reset.
Last Error – Shows the most recent error that was displayed on the controller.
Pressing the reset key will cause the hour timers and water meter to reset to zero.

7.6 Configure Menu

From the Configure menu you can select many different system configuration options.
Home Screen
Configure
Date/Time – Set the current date, date format, time, and time format.
HOA Outputs – Manually control the five relays.
Inputs – Set the input type, drum level, or water meter type and volume.
Gal/Lit – Set the display in Gallons or liters.
Scrolling – Set the time between each timer's status scrolling speed on the home
screen.
Totalizers- View the water meter totalizer values since the last user reset.
Contrast – Set the display contrast.
Password – Set the user password.
Troubleshoot – View the signal inputs in real-time to diagnose wiring problems.
Software Version – Displays the current software version.
Factory Restore – Restore the parameters to factory default.
72-910-23 Rev.F
Page 16 of 30
Date/Time
HOA Outputs
Inputs
Gal/Lit
Scrolling
Totalizers
Contrast
Password
Troubleshoot
Software Ver
Factory Rst
Back | Select
