11.1 Timer Mode Menus

From this menu pick the mode that the inhibitor feed will follow.
Home Screen
Settings
Pulse Timer – See the menu for this function in the following section.
Percent Timer – Set the timer run time period and percentage of the time period.
Example: Cycle Time=60minutes, % Minutes to run=10, the timer will run for 10% of 60
minutes, or 6 minutes every 60 minutes.
28 Day Timer (Biocide) – See the menu for this function in the following section.
Cycle Timer - See the menu for this function in the following section.
11.2 Timer Modes – Pulse Timer Menu
From this menu configure how you want the inhibitor to feed while in pulse timer mode. This
mode uses the water meter input to cause a counter to accumulate a certain volume of water
before the inhibitor is feed. Once the accumulated volume is reached the inhibitor is feed for the
programmed Feed Time.
Home Screen
Settings
Feed Time – Set this value to the amount of time you want the timer to run for when the
water meter accumulator reaches its target.
Accumulator Set – Set this value to the amount of water that needs to accumulate prior
to a timer run time. The units will be in gallons or liters depending on what you set the
water meter units to.
Accumulator Count – This is the current running count of the water meter accumulator.
Water meter – Select which of the five possible water meter inputs will activate the
pulse timer.
72-910-23 Rev.F
Page 22 of 30
Timer 1
Timer 1
√Pulse Timer
Pulse Timer
Percent Timer
28 Day Tmr
Cycle Timer
Back | Select
Feed Time
Accum Set
Accum Count
Water Meter
Back | Select
