7.15 Password Setting

From the Password setting you select the user password that will be required to gain access to
the Configuration and Settings menus. Once the password is set to anything other than 0000 (4-
zeros) the password feature is enabled. To disable password protection return the password to
0000 (4-zeros).
Home Screen
Configure
Password – Set the user password.
Once the password is set the controller will require a password to access any menus. If the
password is lost or unknown you will have to call technical service to gain access to the
controller menus. Please have the controller in front of you when you place the call.

8. Troubleshoot Screen

From the Troubleshot Screen you can view the Microvision control inputs in real-time. This is a
great tool for checking the correct operation of sensors that are attached to the controller.
Home Screen
Configure
Flow input – Water flow switch input (J4 pins 1-2).Flow=closed, No flow = open.
Drum Levels – Inhibitor drum level input Empty=closed, OK=open.
Water Meter – Water meter input (J3 pins 1-3). Open=contact open, closed=contact
closed.
Wk – Revolving week number between one and four. This is used in the biocide
Days/Weeks settings.
Day – Day of week. This is used in the biocide Days/Weeks settings.
Sec - Current clock seconds.
While this screen is displaying information the controller is still functioning normally and relay
outputs may energize without warning due to changing signal inputs.
72-910-23 Rev.F
Page 20 of 30
Change
Password
0000
Cancel |Enter
Password
Ip 1: Open Ip 2: Open
Ip 3: Open Ip 4: Open
Ip 5: Open
Wk: 2 Day:Mon Sec:23
Back | Back
Troubleshoot
