DataMan
8072 Verifier
Quick Reference Guide
2022 August 04
Revision: 6.3.2.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DataMan 8072 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cognex DataMan 8072

Summary of Contents for Cognex DataMan 8072

  • Page 1 ® DataMan 8072 Verifier Quick Reference Guide 2022 August 04 Revision: 6.3.2.3...
  • Page 2 LASER PRODUCT. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE SERIOUS INJURY. To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: This product is intended for industrial use in automated manufacturing or similar applications.
  • Page 3 This device should be used in accordance with the instructions in this manual. All specifications are for reference purposes only and can change without notice. This product is intended for industrial use in automated manufacturing or similar applications. The safety of any system incorporating this product is the responsibility of the assembler of the system.
  • Page 4 Symbols The following symbols indicate safety precautions and supplemental information: WARNING: This symbol indicates a hazard that could cause death, serious personal injury or electrical shock. CAUTION: This symbol indicates a hazard that could result in property damage. Note: This symbol indicates additional information about a subject. Tip: This symbol indicates suggestions and shortcuts that might not otherwise be apparent.

  • Page 5: Product Overview

    Product Overview WARNING: LASER LIGHT, DO NOT STARE INTO BEAM Imager and Lens Optical System Illumination Removable Standoff Trigger (press and release) Lanyard hook Indicator light Communication module insertion point...

  • Page 6: Status Indicators

    Status indicators: Communication: GREEN = good verification RED = bad verification...
  • Page 7 DataMan 8072 Verifier Kits The DataMan 8072 Verifier is available in the following kits: Model number Description DMV-8072V-S-0200U (USA power adapter) DataMan 8072 Verifier Ethernet Kit with Stand: DMV-8072V-S-0200E (EU power adapter) DataMan 8072 Verifier Standoff Ethernet Slide-In Ethernet Cable Attachment...
  • Page 8 Ethernet Cable Attachment POE Injector Basic Calibration Card DMV-8072V-0100 DataMan 8072 Verifier USB Kit DataMan 8072 Verifier Standoff USB Slide-In USB Cable Power Supply Basic Calibration Card DMV-8072V-0000 DataMan 8072 Verifier Kit No Slide-In DataMan 8072 Verifier Standoff Basic Calibration Card...
  • Page 9 DMV-8072VHD-02EU (EU power adapter) DataMan 8072 Verifier-HD Standoff Ethernet Slide-in Ethernet Cable Attachment POE Injector Basic Calibration Card DataMan 8072 Verifier-HD USB Kit with Stand: DMV-8072VHD-S-01 DataMan 8072 Verifier-HD S-model Standoff USB Slide-in USB Cable Power Supply Basic Calibration Card...
  • Page 10 DMV-8072VHD-02U (USA power adapter) DataMan 8072 Verifier-HD Verifier Ethernet Kit with DMV-8072VHD-02E (EU power adapter) Stand: DataMan 8072 Verifier-HD S-model Standoff Ethernet Slide-in Ethernet Cable Attachment Standard Ethernet Cable POE Injector Basic Calibration Card Stand Accessory DataMan 8072V Verifier and stand-off...
  • Page 11 DataMan 8072 Verifier Accessories Ethernet Slide-In DMCM-ENETM-00 Serial/USB 2.0 Slide-In DMCM-USB2EN-00 Power Supply for USB 2.0 Slide-In DM100-PWR-000 POE hub CPS-AC-POE1A-US DMV-8072V-STAND Stand Accessory Stand-off/Nose Cone for 8072V/HD DMV-8072V-SO-0200 DMV-CCC Cognex Basic Calibration Card...
  • Page 12 Applied Image Conformance Calibration Card DMV-DMCC Validation Protocol DM8072V DMV-VP-8072V Cables USB Cable for USB 2.0 Slide-In, 2.5 m DM8500-USBC-02 Ethernet Cable for Ethernet Slide-In, 5 m DM8000-ECABLEC-05 Standard Ethernet Cable CBL-C10E...
  • Page 13 1. Connect the slide-in to the verifier, and tighten the screws to lock the slide- 2. Insert the plug. Slide the cable lock up to the verifier, and twist the cable lock in place. Note: Disconnect the DataMan 8072 Verifier from power or remove the battery before inserting/removing the communication modules.

  • Page 14: Installation

    All cable connectors are "keyed" to fit the connectors on the DataMan system; do not force the connectors or damage may occur. 1. After installing the software, connect the DataMan 8072 Verifier to your PC. 2. Launch the DataMan Setup Tool and click Refresh.
  • Page 15 5A maximum Inrush current peak Duration: approx. 30μs Ethernet 10/100 Base-T FULL/HALF DUPLEX, IEEE 802.3 DataMan 8072 Verifier Imager Specifications Specification DataMan 8072 Verifier Imager 1/3 inch CMOS global shutter Image Sensor 3.75 μm square pixels Image Sensor Properties...
  • Page 16 LED Wavelengths for DataMan 8072 Verifier Note: The data below refer to the LED Illumination accessory of the reader, not to the LED indicators. The following table shows LED types and the related wavelengths: λ [nm]...

  • Page 17: Regulations And Conformity

    Regulations and Conformity The DataMan 8072 Verifier has Regulatory Model R00071, and meets or exceeds the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Please read these guidelines carefully before using your device.
  • Page 18 Safety and Regulatory This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take immediate measures. This equipment complies with the essential requirements of the EU Directive 2014/30/EU.

  • Page 19: Led Safety Statement

    LED Safety Statement CAUTION: Illumination and Lens assembly: This device has been tested in accordance with IEC 62471-1:2008 and has been certified to the limits of Risk Group 2. Possibly hazardous optical radiation emitted from this product. Do not stare at the operating lamp. May be harmful to the eyes. Laser Safety Statement WARNING: Complies with FDA performance standards for laser products...
  • Page 20 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
  • Page 21 Copyright © 2021 Cognex Corporation. All Rights Reserved.
