Attach Board Rim; Rim Attachment - SPALDING NBA Arena Portable System Manual

Item Qty. Part No. Description
32 1 Backboard
40 1 Rim
41 1 Net
#R1 (4)
(2) Wrenches
1/2" 9/16"
AND/oR
(2) Socket Wrenches and Sockets
1/2" 9/16"
SecTIoN e: ATTACH BOARD RIM
RIM ATTAcHMeNT HARDWARe AND BAG
HARDWARE LIST AND IDENTIFIER
ToolS ReQuIReD FoR THIS SecTIoN
extension
222700
Item Qty. Part No.
R1 4 201611
R2 4 203309
R3 4 203100
#R2 (4)
Sawhorse or Support Table
24
Description
Bolt, Hex-Flange, 5/16-18 x 3" Long
Washer, 3/8, 1: O.D.
Nut, Hex-Flange, 5/16-18
#R3 (4)
phillips Screwdriver
