SPALDING NBA Arena Portable System Manual page 10

5.
Correctly identify each pole section (TOP and BOTTOM). See IlluSTRATIoN BeloW.
NoTe: please disregard pole identification labels.
6.
Use pencil or tape and mark a line 4" from top of bottom pole. ASSeMBle Top pole To THIS MARKeD
lINe. While maintaining alignment, bounce bottom pole section (2) into top section (3) using a wood scrap
as shown until the top pole has a 4" MINIMuM overlap of the bottom pole. See cAuTIoN! diagram below.
IMpoRTANT!
NoTe oRIeNTATIoN
oF eAcH pole SecTIoN.
position each pole section so that the
FRoNT and ReAR faces match the
illustration when assembled.
See DeTAIl vIeWS BeloW
WARNING!
TWo cApABle ADulTS ReQuIReD
FoR THIS pRoceDuRe. FAIluRe To
FolloW THIS WARNING coulD
ReSulT IN SeRIouS INjuRy
AND/oR pRopeRTy DAMAGe.
ReAR FAce
BoTToM
pole
ReAR FAce
Top
pole
3
Top
NoTe
BRAcKeT
locATIoN
NoTe
Hole
locATIoN
4" (10 cm)
2
ReAR FAce
BoTToM
pole
3
ReAR FAce
Top
pole
10
BoTToM
cAuTIoN!
WHEN PROPERLY ASSEMBLED,
THE POLE SECTIONS SHOULD
HAVE A 4" MINIMuM OVERLAP.
ASSEMBLE TOP POLE TO LINE
MARKED 4" FROM TOP OF
BOTTOM POLE
FRoNT FAce
BoTToM
pole SecTIoN
2
4" MARK
lINe
3
FRoNT FAce
Top
pole SecTIoN
Wood Scrap - 6" x 6" minimum
(NoT SupplIeD)
2
