Pressure
Quartz High-Pressure Sensor
for Ballistic Pressure Measurement to 6 000 bar
The front sealed high pressure sensor surtable for ballistic pres-
sure measurement up to 6 000 bar.
•
NATO Standard
•
Extremely long service life
•
Very good long term stability
Description
Compared to the shoulder sealing used so far, the front seal-
ing technically improves the sensor considerably. The result-
ing main advantages are a considerably lower mechanical and
thermal stress of the sensor, no mounting gap (small dead
volume) and a largely reduced surface pressure in the sealing
part.
The Type 6215... has been accepted by NATO as the successor
to Kistler Type 6203 (AC/225 LG/3-SG/1). The existing NATO
Standardization Agreements (STANAGs) and Manuals of Proof
and Inspections (MOPIs) are being amended accordingly.
Application
Use for all ballistic measurements. Depending on the measur-
ing configuration, the sensor can be installed with an addi-
tional thermal protection shield or a diaphragm protection.
Mounting
The front seal allows the use of an additional attachment.
Figure 3 shows the installation with thermal protection shield
Type 6565A and thermal protective plate Type 1181A to re-
duce thermal shock error. For measurements in which the sen-
sor is exposed to heat over the entire pressure profile (e.g. in
pressure bombs and cartridge chambers).
Figure 4 shows the installation with diaphragm protector Type
6567. Recommended for measurements at the case mouth
and along the measuring barrel as protection against mechani-
cal damage from metal fragments and powder particles. It is
essential to follow the operating instructions when machining
the measuring hole and for installation.
This information corresponds to the current state of knowledge. Kistler reserves
the right to make technical changes. Liability for consequential damage resulting
from the use of Kistler products is excluded.
Technical Data
Range
Calibrated partial range
Overload
Sensitivity
Natural Frequency
Rise time
Linearity for all ranges
Acceleration sensitivity
axial
transverse
Shock resistance
axial
transverse
Temperature coefficient
of the sensitivity
Operating temperature range
Capacitance
Insulation resistance at 20 °C
Tightening torque
Weight
©2007, Kistler Instrumente AG, Eulachstr. 22, 8408 Winterthur, Switzerland
Tel +41 52 224 11 11, Fax +41 52 224 14 14, info@kistler.com,
Type 6215...
bar
0 ... 6 000
bar
0 ... 600
bar
pC/bar
kHz
µs
%FSO
bar/g
<0,002
bar/g
<0,005
g
25 000
g
10 000
%/°C
°C
–50 ... 200
pF
Ω
N·m
g
Page 1/2
www.kistler.com
6 600
–1,4
>240
1
±1
±0,02
≈8
>10
13
20
12
